Factory Floating Pneumatic Rubber Fenders 0.5-4.5m Black ISO Certified Adaptable Tide Marine Boats-Direct Sell Corrosion Proof

Pneumatic rubber fenders, also known as Yokohama fenders, are manufactured using rubber and multiple layers of rubber-dipped tire fabric. They serve as leading anti-collision devices for marine applications worldwide.

Floating pneumatic rubber fenders are constructed from synthetic-cord-reinforced rubber sheets with compressed air inside. The internal air enables them to float on water and function as shock absorbers between ships (ship-to-ship) or between ships and berthing structures during docking operations.

• Reinforced synthetic-tire-cord layers providing strong stability, heat resistance, fatigue resistance, and impact load resistance
• No mold vulcanization with surrounding molding process
• Single-formed rubber capsule wall eliminates secondary joint weak points
• Thin, soft walls with excellent contact deformation performance and large energy absorption
• Superior adaptability to inclined contact up to 15 degrees
• Floating capability accommodates multi-directional ship docking
• Easy installation and handling

Ships typically make initial contact with docks or other vessels at oblique angles during STS operations. Unlike solid rubber or foam fenders, inflatable rubber fenders maintain rated reaction force and energy absorption even at inclined compression up to 15 degrees.

Zhonghaihang Pneumatic Rubber Fenders consist of outer rubber, reinforcement synthetic-tire-cord layer, and inner rubber, all firmly vulcanized together.

• Outer Rubber: Protects cord layers and inner rubber from abrasion and external forces with sufficient tensile and tear resistance
• Reinforcement Layer: Synthetic-tire-cord layer maintains internal air pressure
• Inner Rubber: Seals pressurized air inside the fender
• Safety Features: Fenders ≥2500mm diameter include safety valves for pressure release during over-compression

• Maintain fender pressure within ±5% of standard; check air pressure every three months
• Avoid contact with sharp objects
• When not in use: clean, dry, fill with proper compressed air, store in cool, dry, ventilated area
• Storage area should be away from heat, acid, alkali, oil, and grease
• Do not fold or stack during storage

Qingdao Zhonghaihang Shipping Supply Co., Ltd is an integrated company specializing in product manufacturing, technological innovation, research and development, sales, and service. Founded in 2015, the company has developed into a professional manufacturer of launching airbags, dock collision avoidance systems, and ship collision avoidance facilities.

Our facilities cover over 20,000 square meters with approximately 10,000 square meters of production area. Supported by a professional technical team, we maintain an extensive sales network and comprehensive after-sales service system. Our products are exported to more than 80 countries and regions, earning recognition for high quality and reliable performance.

We hold ISO9001 quality management system certification, high-tech product certification, environmental management system certification, and occupational health management system certification. All products receive quality authentication from CCS, BV, GL, ABS, LG, and other recognized authorities.

Committed to continuous improvement and technological innovation, Zhonghaihang pursues excellence in quality to build a world-class brand.
