Hot Selling Yokohama Pneumatic Rubber Fender Natural Rubber Marine Vessel Ship Parts Accessory for Boats

Brand Name:	ZHH
MOQ:	1 piece
Price:	$1,200-1,300 / piece

Detail Information

Product Description

Detail Information

Place of Origin:

Shandong, China

Part:

Fender

Product Name:

Pneumatic Fender

Material:

Rubber

Shape:

Cylindrical

Size:

0.5-4.5m

Color:

Black

Certificate:

ISO17357

MOQ:

Delivery Time:

7 Days

Highlight:

Yokohama pneumatic rubber fender

marine vessel rubber fender

natural rubber boat fender

Product Description

Products Description

Product Name	Pneumatic rubber fender
Product Model	cq1-1
Brand	ZHH
Diameter	500-4500mm
Standard	ISO17357:2014
Technology	Explosion Proof, Overall Winding, Anti-Aging, Large energy absorption
Specification	N/A
Packaging Details	pallet

Pneumatic rubber fender also called yokohama fender, made by rubber & multi layers of rubber-dipped tyre fabric, is a leading anti-collision device for marine application in the world today.

Floating pneumatic rubber fenders can be easily handled and installed with guy-rope or guy-chain because of their lightweight. It can resist the shearing force and maintain energy absorption level under inclined compression up to 15 degrees. Meanwhile, provide low and comparatively even hull pressure. Consisted of several synthetic-cord layers and tough abrasion-resistant rubber, they have consistent performance even under rough conditions and cyclic load. The maintenance cost and damage risk are minimized too.The best material also ensures self-buoyancy and extremely long service life. Pneumatic fenders are available from 500 mm to 4,500 mm in diameters, and from 500 mm to 9,000 mm in length. All sizes of pneumatic rubber fenders are available as sling-type or with a heavy-duty chain & tire net. We also supply vertical hydro pneumatic fenders for submarines. Note: The floating pneumatic rubber fenders have sometimes been colloquially referred to as "Yokohama Fenders" or "Yokohama type fenders" - ISO 17357:2014 Ships and marine technology - High-pressure floating pneumatic rubber fenders.

Advantages of Pneumatic rubber fender

1 Choose reinforce synthetic-tire-cord layers 2 No mold vulcanization and attach surrounding molding process 3 High energy absorption and low reaction force 4 Good adaptability to tilt in contact 5 Floating on the surface of the water, ship swaying can apply 6 Easy installation 7 It can accommodate the docking of ships in all directions

Advantages at Inclined Berthing

Ships usually make initial contact with the dock or another ship on STS operations at an oblique angle.

In the case of solid rubber fenders or foam fenders, rated reaction force and energy absorption decreases considerably at inclined compression compared with parallel compression. In order to compensate for the decrease of energy absorption at inclined compression, it is necessary to use larger sizes in the case of solid rubber fenders or foam fenders.

Application

In ports with extreme tidal variations Ship-to-ship berthing Offshore platform protection Oil&Gas(typically FSRU) Ship-to-dock berthing

Product Structure

Pneumatic Rubber Fenders of Zhonghaihang made of an outer rubber, reinforcement synthetic-tyre-cord layer, and inner rubber,vulcanized firmly.

[A]. the outer rubbers are used to protect the cord layers and inner rubber from abrasion and other external forces. This rubber compound have sufficient tensile and tear resistance strength to withstand anticipated weather conditions and severe usage.

[B]. the reinforcement synthetic-tyre-cord layer strong enough to maintain the internal air pressure of the fender.
[C]. the inner rubber layer seals the pressurized air inside the fender.

[D]. fenders of diameter 2500mm and larger equipped with safety valve for releasing excess internal pressure when the fenders are over-compressed accidentally.

Fender assembly for the end of metal, by inside and outside the two flanges with bolts, nut clamping, center is a valve, its structure is similar to automobile tire valve.

Pneumatic rubber fender precautions

1 Fender pressure should be kept in the standard air pressure in the± 5% range, and once every three months to check air pressure, deflated or fill gas up to standard in a timely manner. 2 Avoid touching the sharp things 3 When Long time not use, should wash to dry, filled with right amount of compressed air, placed in a cool dry ventilated place. 4 Storage place away from heat, acid and alkali, oil and grease 5 When store, shall not be folded and piled up

Pneumatic rubber fender parameter table

Installation Method

Production Line

Company Profile

Qingdao Zhonghaihang Shipping Supply Co.,Ltd

Qingdao Zhonghaihang Shipping Supply Co., Ltd is a company integrating product manufacturing, technological innovation, research and development, sales and service. Founded in 2015, after years of unremitting efforts, the company has now developed into a professional company that produces launching airbags, dock collision avoidance, and ship collision avoidance facilities.

Our company covers an area of more than 20,000 square meters, production construction area of about 10,000 square meters, relying on its own professional and technical team to improve the sales network and after-sales service system, products are exported to more than 80 countries and regions, with high-quality and reliable quality, sincere first-class service has won the praise of customers and the recognition of the same industry.

Our company has obtained ISO9001 quality management system certification, high-tech product certification, environmental management system certification, occupational health management system certification, etc.All products get quality authentication from CCS, BV, GL, ABS, LG, etc. Over the years, the company has always adhered to the mission of "escort all the way" and adhered to the concept of "customer first, quality first, service guarantee, innovation and development". Along the way, Zhonghaihang has never forgotten its original intention, actively carried out business such as hull fenders and airbags,earnestly fulfilled social responsibilities, unswervingly took the road of high-quality and sustainable development,and committed to achieving win-win economic, social and ecological benefits.Zhonghaihang will make unremitting efforts for the progress of its own industry.

Why Choose Us

1.Compliance with ISO17357-2014
2.Factory cost price

3.On-Time delivery

4. Flexible MOQ
5.OEM and ODM
6.Technical support
7.Simple and low cosy installation
8.Long liftspan
9.Good after-sales service
10.Low reaction force and large energy absorption

FAQ

A) How could I get a sample? Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order.

B) Sample time? Existing items: Within 7 days.

C) Whether you could make our brand on your products? Yes. We can print your Logo on both the products and the packages.

D) Whether you could make your products by our color? Yes, The color of products can be customized if you can meet our MOQ.

E) How to guarantee the quality of your products? 1) Strict detection during production. 2) Strict sampling inspection on products before shipment and intact product packaging ensured.
