CKJV80 150/250V Marine Cables Crosslinked Polyethylene Insulated

Brand Name:	JIANGNAN CABLE
Model Number:	CKJV80/DA/SA、CKJV90/DN SA、CKJPJ80/SC、 CKJPJ90/SC 、CKJPF80/SC、CKJPF90/SC CKJV80/NA、CKJV90/NA、CKJPJ80/ NC、 CKJPJ90/NC 、CKJPF80/ NC、CKJPF90/NC
MOQ:	100 Meter
Price:	US$1.00~US$20.00
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CCS BV

Item Name:

Marine Cable

Application:

Power, Lighting, Communication And Control Systems For Ships And Ocean Engineering

Certificates:

CCS/BV

High Purity Electrolytic Copper:

Selecting 1# Electrolytic Copper With A Copper Content Of More Than 99.95%

Steel Tape/Steel Wire Armored:

Resistant To A Wide Range Of External Stresses And Erosion

Copper Shield:

Good Conductivity And Shielding Properties

PVC/XLPE:

Good Electrical Insulation Properties, Can Effectively Prevent Current Leakage

Fireproof:

Excellent Fireproof Performance

Characteristics:

High Resistance To Pressure, Abrasion, Corrosion Etc.

Packaging Details:

DRUM

Highlight:

CKJV80 150/250V Marine Cables

Marine Cables Crosslinked Polyethylene Insulated

Crosslinked Polyethylene Marine Cable

Product Description

CKJV80/DA/SA 150/250V Rated Voltage Crosslinked Polyethylene Insulated Marine Control Cable with 90°C Operating Temperature

Rated voltage 150/250V crosslinked polyethylene insulated Marine control cable

Executive Standard

This product implements: IEC60092-376 standard.

Cable Categories and Types

CKJV/DA/SA/NA: XLPE insulated polyvinyl chloride sheathed marine control cable

CKJV80/DA/SAVNA: XLPE insulated polyvinyl chloride inner sheathed copper wire braided ammoring marine control cable

CKJV90/DA/SA/NA: XLPE insulated PVC inner sheathed steel wire braided armoring control cable for marine

CKJV82/DASA/NA: XLPE insulated PVC inner sheathed copper wire braided armored PVC outer sheathed marine control cable

CKJV92/DA/SANA: XLPE insulated PVC inner sheathed wire braided armoring PVC outer sheathed Marine control cable

CKJPJ/SC/NC: XLPE insulated cross-linked polyolefin outer sheathed marine control cable

CKJPJ80/SC/NC: XLPE insulated cross-linked polyolefin inner sheathed copper wire braided ammoring control cable for marine

CKJPJ90/SC/NC: XLPE insulated crosslinked polyolefin inner sheathed wire braided ammoring control cable for marine

CKJPJ85/SC/NC: XLPE insulated crosslinked polyolefin inner sheathed copper wire braided armoring crosslinked polyolefin outer sheathed marine control cable

CKJPJ95/SC/NC: XLPE insulated crosslinked polyolefin inner sheathed cooper wire braided armoring crosslinked polyolefin outer sheathed marine control cable

CKJPF/SC/NC:Cross-linked polyethylene insulated polyolefin sheathed marine control cable

CKJPF80/SC/NC: XLPE insulated polyolefin inner sheathed copper wire braided armoring control cable for marine

CKJPF90/SC/NC: Crosslinked polyethylene insulated polyolefin inner sheathed steel wire braided armoning control cable for marine

CKJPF86/SC/NC: Crosslinked polyethylene insulated polyolefin inner sheathed copper wire braided armored polyolefin outer sheathed marine control cable

CKJPF96/SC/NC: Crosslinked polyethylene insulated polyolefin inner sheathed copper wire braided armored polyolefin outer sheathed marine control cable

Product Application

This product is suitable for general control devices of water structures such as cabins and offshore oil platforms.

Cable Parameters

Rated voltage 150/250V crosslinked polyethylene insulated Marine control cable
No.of cores ×sectional area	CKJV80/DASA,CKJV90/DA/SA,CKJPJ80/SC, CKJPJ90/SC,CKJPF80/SC,CKJPF90/SC				CKJV80/NA,CKJV90/NA,CKJPJ80/NC, CKJPJ90/NC,CKJPF80/NC,CKJPF90/NC
No.of cores ×sectional area	Over diam.mm		Approx.weight		Over diam.mm		Approx.weight
No.×mm²	Nom.	Max	TYPE 80	TYPE 90	Nom.	Max	TYPE 80	TYPE 90
2*0.75	7.7	9.5	86	84	8.7	10.5	102	99
3*0.75	8.0	9.9	99	96	9.1	10.9	116	112
4*0.75	8.6	10.5	113	110	9.8	11.7	139	136
5*0.75	9.3	11.2	135	132	10.8	12.8	161	157
7*0.75	10.0	12.0	155	151	11.7	13.7	181	177
10*0.75	12.6	14.8	212	207	14.8	17.0	262	255
12*0.75	13.0	15.2	234	229	15.4	17.7	290	283
14*0.75	13.8	16.0	260	255	16.2	18.4	329	322
16*0.75	14.4	16.8	286	281	17.2	19.5	362	354
19*0.75	15.3	17.7	330	323	18.0	20.4	425	414
24*0.75	17.8	20.4	434	423	21.0	23.6	527	514
27*0.75	18.2	20.8	491	478	21.4	24.1	597	583
30*0.75	18.8	21.4	527	514	22.2	24.8	641	626
33*0.75	19.4	22.2	550	538	23.0	25.7	669	654
37*0.75	20.3	23.1	593	580	24.2	27.0	722	707
2*1	8.1	9.9	97	94	9.1	10.9	113	110
3*1	8.5	10.3	112	108	9.5	11.4	135	131
4*1	9.1	11.0	130	127	10.3	12.2	157	153
5*1	9.8	11.8	156	152	11.4	13.3	182	178
7*1	10.8	12.8	180	176	12.3	14.3	215	210
10*1	13.4	15.6	247	242	15.8	18.0	309	301
12*1	13.8	16.0	277	272	16.3	18.5	343	336
14*1	14.6	16.9	319	312	17.0	19.3	381	373
16*1	15.6	17.9	360	353	18.1	20.4	444	433
19*1	16.3	18.7	402	395	19.0	21.4	505	493
24*1	19.0	21.6	526	514	22.2	24.8	627	613
27*1	19.4	22.0	582	569	22.7	25.3	694	679
30*1	20.0	22.7	640	626	23.6	26.3	762	747
33*1	21.0	23.7	658	644	24.7	27.4	799	784
37*1	21.7	24.5	725	711	25.6	28.4	864	848
2*1.5	9.1	10.9	121	118	10.1	11.9	145	141
3*1.5	9.5	11.4	148	144	10.8	12.6	168	164
4*1.5	10.5	12.4	174	170	11.7	13.6	198	193
5*1.5	11.4	13.3	202	197	12.9	14.8	237	233
7*1.5	12.3	14.3	242	237	14.1	16.1	274	268
10*1.5	15.8	18.0	347	340	18.0	20.2	417	406
12*1.5	16.3	18.5	389	381	18.5	20.8	478	466
14*1.5	17.2	19.5	457	446	19.4	21.7	531	518
16*1.5	18.1	20.4	516	505	20.7	23.0	586	573
19*1.5	19.0	21.4	577	564	21.7	24.1	669	655
24*1.5	22.2	24.8	717	703	25.6	28.2	832	816
27*1.5	22.7	25.3	810	794	26.1	28.8	975	953
30*1.5	23.8	26.5	876	860	27.2	29.9	1053	1030
33*1.5	24.7	27.4	922	906	28.3	31.0	1105	1082
37*1.5	25.6	28.4	1000	984	29.3	32.1	1198	1175
2*2.5	9.9	11.7	157	153	11.1	12.9	176	172
3*2.5	10.6	12.4	187	183	11.7	13.5	209	205
4*2.5	11.5	13.4	224	219	12.8	14.7	257	252
5*2.5	12.5	14.4	270	265	14.1	16.1	302	296
7*2.5	13.8	15.8	319	314	15.5	17.5	375	367
10*2.5	17.6	19.8	482	470	19.6	21.8	547	534
12*2.5	18.1	20.4	555	544	20.4	22.6	616	603
14*2.5	19.0	21.3	622	609	21.4	23.7	704	691
16*2.5	20.2	22.5	691	678	22.5	24.9	782	768
19*2.5	21.2	23.6	793	779	24.1	26.5	882	867
24*2.5	25.0	27.6	989	973	28.2	30.8	1153	1131
27*2.5	25.5	28.2	1152	1130	28.8	31.4	1298	1274
30*2.5	26.6	29.3	1248	1225	30.0	32.7	1407	1382
33*2.5	27.6	30.3	1321	1299	31.1	33.9	1488	1464
37*2.5	28.6	31.4	1439	1416	32.5	35.3	1621	1595
Note: Data above only for reference.confirmation needed by our technical department. We reserve the right to alter all information without notice.

Technical Characteristics

The rated AC voltage of the cable is 150/250V;
The allowable long-term operating temperature of the cable conductor is 90℃
The flame retardant performance of the cable conforms to IEC60332-1-2 or IEC60332-3-22 standards
The fire resistance conforms to IEC60331-21 standard
The minimum bending radius of the cable is 6 times the diameter of the cable

Identification

Insulated core: white insulated with black numbering
Sheath printed with factory name, type, voltage, specification, length mark, etc.

Structure Diagram
