Flameproof Marine Control Cable CKEF82 DA SA Boat Motor Control Cables

Brand Name:	JIANGNAN CABLE
Model Number:	CKEF82/DA/SA、CKEF92/DA/SA、CKEV82/DA/SA、CKEV92/DA/SA、CKEPJ85/SC、CKEPJ95/SC、CKEPF86/SC、CKEPF96/SC CKEF82/NA、CKEF92/NA、CKEV82/NA、CKEV92/NA、CKEPJ85/NC、CKEPJ95/NC、CKEPF86/NC、CKEPF96/NC
MOQ:	100 Meter
Price:	US$1.00~US$20.00
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CCS BV

Cable Type:

Marine Control Cable

Implement Standard:

IEC60092-376

Usage:

General Control Devices Of Water Structures Such As Cabins And Offshore Oil Platforms

Rated AC Voltage:

150/250V

Fire Resistance:

IEC60331-21

Insulated Core:

Ethylene Propylene

Packaging Details:

DRUM

Highlight:

Flameproof Marine Control Cable

Marine Control Cable CKEF82

SA Boat Motor Control Cables

Product Description

CKEF82/DA/SA Marine Control Cable with 150/250V Rated Voltage and Flame Retardant Performance for 90°C Operating Temperature

Ethylene Propylene insulated Marine Control Cable at Rated Voltage of 150/250V

Executive Standard

This product implements: IEC60092-376 standard.

Cable Categories and Types

CKEF/DA/SA/NA:Ethylene propylene insulated neoprene sheathed marine control cable

CKEF80/DA/SA/NA:Ethylene propylene insulated neoprene inner sheathed copper wire braided armouring marine control cable

CKEF90/DA/SA/NA:Ethylene propylene insulated neoprene inner sheathed steel wire braided armouring control cable for marine

CKEF82/DA/SA/NA:Etylene propylene insulated neoprene inner sheathed copper wire braided armonng polyviny chlonde outer sheathed marine control cable

CKEF92/DA/SA/NA:Ethylene-propylene insulated neoprene nner sheathed wire braided armoring polwvinylchlonide outer sheathed manne control cable

CKEV/DA/SA/NA:Ethylene propylene insulated polyvinyl chloride sheathed marine control cable

CKEV80/DA/SA/NA:Ethylene propylene insulated polywinyl chlonde inner sheathed copper wire braided armoring marine control cable

CKEV90/DA/SA/NA:Ethylene propylene insulated polyvinyl chloride inner sheathed steel wire braided armoring for marine control cable

CKEV82/DA/SA/NA:Ethylene propylene insulated PVCinner sheathed copper wire braided armored PVC outer sheathed marine control cable

CKEV92/DA/SA/NA:Ethylene propylene insulated PVC inner sheathed wire braided amored PVC outer sheathed manne control cable

CKEPJ/SC/NC:Ethylene-propylene insulated cross-linked polyolefin outer sheathed marine control cable

CKEPJ80/SC/NC:Ethylene propylene insulated cross-inked polyolefin inner sheathed copper wire braided armored marine control cable

CKEPJ90/SC/NC:Ethylene propylene insulated croSs-linked polyolefin inner sheathed steel wire braided armored marine control cable

CKEPJ85/SC/NC:Ethylene propylene insulated cros-linke polyolefininner sheathed copper wire braided rmored cross-inked polyolfin outer sheathed marine ontrol able

CKEPJ95/SCNC:Ethylene propylene insulated cross-inked polyolefn inner sheathed stee wire braided armored cross-inked polyolfn outer sheatned marine control cable

CKEPF/SC/NC:Ethylene propylene insulated polyolefin outer sheathed marine control cable

CKEPF80/SC/NC:Ethylene propylene insulated polyolefin inner sheathed copper wire braided armored marine control cable

CKEPF90/SC/NC:Ethylene propylene insulated polyolefin inner sheathed steel wire braided armored marine control cable Type SC NCCKEPF86/SC/NC:Ethylene propylene insulated polyolefin inner sheathed copper wire braided armored polyolefin outer sheathed marine control cable

CKEPF96/SC/NC:Ethylene propylene insulated polyolefin inner sheathed stee wire braided armored polyolefin outer sheathed marine controlcable

Product Application

This product is suitable for general control devices of water structures such as cabins and offshore oil platforms.

Cable Parameters

Ethylene Propylene insulated Marine Control Cable at Rated Voltage of 150/250V
No.of cores ×sectional area	CKEF82/DA/SA,CKEF92/DA/SA,CKEV82/DA/SA,CKEV92/DA/SA,CKEPJ85/SC,CKEPJ95/SC,CKEPF86/SC,CKEPF96/SC				CKEF82/NA,CKEF92/NA,CKEV82/NA,CKEV92/NA,CKEPJ85/NC,CKEPJ95/NC,CKEPF86/NC,CKEPF96/NC
No.of cores ×sectional area	Over diam.mm		Approx.weight		Over diam.mm		Approx.weight
No.xmm²	Nom.	Max	TYPE 82/85/86	TYPE 92/95/96	Nom.	Max	TYPE 82/85/86	TYPE 92/95/96
2*0.75	10.0	12.0	129	126	10.8	12.8	143	140
3*0.75	10.4	12.4	147	144	11.2	13.3	170	166
4*0.75	11.1	13.1	182	179	12.2	14.3	194	190
5*0.75	11.6	13.7	205	201	12.8	15.0	220	215
7*0.75	12.7	14.9	240	236	13.9	16.1	275	270
10*0.75	15.6	18.0	333	328	17.5	20.0	384	376
12*0.75	16.0	18.4	377	370	17.9	20.5	420	413
14*0.75	16.8	19.4	422	415	18.9	21.6	470	462
16*0.75	17.7	20.4	459	452	19.8	22.5	536	525
19*0.75	18.5	21.2	521	513	20.6	23.4	606	594
24*0.75	21.8	24.8	667	654	24.6	27.6	785	771
27*0.75	22.2	25.2	791	777	25.0	28.0	865	850
30*0.75	23.3	26.4	843	829	26.2	29.3	941	925
33*0.75	24.0	27.1	869	855	27.0	30.2	971	956
37*0.75	24.8	28.0	936	921	28.1	31.3	1045	1029
2*1	10.4	12.4	141	138	11.2	13.2	162	158
3*1	10.8	12.8	176	173	11.7	13.7	186	183
4*1	11.5	13.6	202	198	12.7	14.8	214	210
5*1	12.1	14.2	228	224	13.4	15.5	243	238
7*1	13.3	15.5	270	266	14.5	16.7	306	301
10*1	16.4	18.7	388	381	18.3	20.8	429	421
12*1	17.1	19.7	437	430	18.8	21.3	481	474
14*1	17.8	20.5	480	473	19.8	22.4	554	543
16*1	18.6	21.3	534	526	20.7	23.4	616	604
19*1	19.7	22.4	634	622	22.2	25.0	685	673
24*1	23.4	26.4	819	806	25.7	28.7	887	873
27*1	23.8	26.8	901	887	26.7	29.7	1009	994
30*1	24.5	27.6	981	966	27.5	30.6	1082	1065
33*1	25.3	28.4	999	984	28.5	31.7	1119	1103
37*1	26.3	29.5	1094	1079	29.7	32.9	1244	1223
2*1.5	11.4	13.4	182	178	12.4	14.4	191	187
3*1.5	11.9	13.9	211	207	12.9	15.0	222	218
4*1.5	12.9	15.0	247	243	13.9	16.0	275	271
5*1.5	13.6	15.7	299	294	14.7	16.8	315	310
7*1.5	14.9	17.1	357	352	16.3	18.4	391	384
10*1.5	18.7	21.2	535	524	20.4	23.0	582	570
12*1.5	19.4	22.0	591	580	21.6	24.2	642	630
14*1.5	20.2	22.9	663	652	23.0	25.6	709	696
16*1.5	21.7	24.4	726	713	24.0	26.7	832	818
19*1.5	23.1	25.9	868	854	25.1	27.9	927	912
24*1.5	26.8	29.8	1064	1049	29.5	32.6	1191	1170
27*1.5	27.2	30.3	1246	1224	30.1	33.1	1335	1312
30*1.5	28.3	31.4	1337	1315	31.0	34.1	1469	1445
33*1.5	29.4	32.6	1385	1363	32.8	36.3	1487	1464
37*1.5	30.4	33.6	1498	1476	33.9	37.5	1649	1625
2*2.5	12.4	14.4	214	210	13.2	15.2	223	219
3*2.5	12.9	15.0	255	250	13.8	15.8	281	277
4*2.5	13.9	16.0	316	312	15.0	17.1	332	327
5*2.5	14.7	16.8	364	359	16.0	18.2	395	388
7*2.5	16.3	18.4	468	461	17.8	20.1	492	485
10*2.5	20.4	23.0	678	665	23.0	25.6	714	702
12*2.5	21.6	24.2	757	744	23.6	26.3	853	840
14*2.5	23.0	25.6	866	853	24.7	27.4	944	930
16*2.5	24.0	26.7	981	967	26.0	28.8	1035	1020
19*2.5	25.1	27.9	1101	1086	27.6	30.5	1181	1165
24*2.5	29.5	32.6	1430	1408	32.6	36.0	1514	1491
27*2.5	30.1	33.1	1621	1597	33.2	36.7	1714	1689
30*2.5	31.0	34.1	1743	1719	34.3	37.8	1889	1863
33*2.5	32.8	36.3	1820	1796	35.6	39.2	1931	1905
37*2.5	33.9	37.5	1977	1952	37.0	40.7	2141	2114
Note:Data above only for reference,confirmation needed by our technical department.We reserve the right to alter all information without notice.

Technical Characteristics

The rated AC voltage of the cable is 150/250V;
The allowable long-term operating temperature of the cable conductor is 90℃
The flame retardant performance of the cable conforms to IEC60332-1-2 or IEC60332-3-22 standards
The fire resistance conforms to IEC60331-21 standard
The minimum bending radius of the cable is 6 times the diameter of the cable

Identification

Insulated core: white insulated with black numbering
Sheath printed with factory name, type, voltage, specification, length mark, etc.

Structure Diagram
