| Brand Name: | JIANGNAN CABLE |
| Model Number: | CHJVP/DA/SA、CHJPJP/SC、CHJPFP/SC CHJVP/NA、CHJPJP/NC、CHJPFP/NC |
| MOQ: | 100 Meter |
| Price: | US$1.00~US$20.00 |
| Payment Terms: | T/T |
| CHJV/DA/SA/NA: | XLPE insulated PVC sheathed marine communication cable DA SA NA type |
| CHJVP/DA/SA/NA: | XLPE insulated pair twisted individual screen polyvinyl chloride sheathed marine communication cable DA SA NA type |
| CHJV80/DASA/NA: | XLPE insulated polyvinyl chloride inner sheathed copper wire braided armoring communication cable for marine type DA SANA |
| CHJVP80/DAVSA/NA: | XLPEinsulated pai twisted individual screen polyviny choride inner sheathed copper wire braided amored for marine communication cable type DASA NA |
| CHJV90/DA/SA/NA: | XLPE insulated polyvinyl chloride inner sheathed steel wire braided armored communication cable for marine type DA SA NA |
| CHJVP90/DA/SA/NA: | XLPE insulated pai twisted indvidual screen polyviny chorideinner sheathed stel wre braided armored for marine communiction cable type DASA NA |
| CHJ82/DA/SA/NA: | XLPE insulated copper wire braided armoring PVC sheathed marine communication cable DA SA NA type |
| CHJV82/DASA/NA: | XLPE insulated PVCinner sheathed copper wire braided armoring PVC outer sheathed marine communication cable DA SA NA type |
| CHJP82/DASA/NA: | XLPE insulated pair twisted individual screen copper wire braided armoring PVC sheathed marine communication cable DA SANA type |
| CHJVP82/DASA/NA: | XLPE insulated twisted individual screen PVCinner sheathed copper wire braided amoning PVC outer sheathed marine communication cable |
| CHJV92/DASA/NA: | XLPE insulated PVCinner sheathed wire braided armoring PVC outer sheathed Marine communication cable DASA NA type |
| CHJVP92/DA/SA/NA: | XLPEinsulated pair twisted individual screen PVC inner sheathed wire braided armoring PVCouter sheathed marine communication cable DASA NA type |
| CHJPJ/SC/NC: | XLPE insulated crosslinked polyolefin outer sheathed marine communication cable SC NC type |
| CHJPJP/SC/NC: | Cross-Iinked polyethylene insulated pai twisted individual screen cross-linked polyolefin outer sheathed marine communication cable |
| CHJPJ80/SC/NC: | Cross-lnked polethylene inslated pai twisted individual screen cros-lnked polyolefininner sheathed copper wire braided armored marine communication cable |
| CHJPJP80/SC/NC: | CrosS-linked polyethylene insulated pair twisted indvidual scren cross-Inked polyolefn inne sheathe operwie braided armored marine commuicafion cable |
| CHJPJ90/SC/NC: | Cross-inked polyethylene insulated cross-linked polyolefin inner sheathed steel wire braided armored marine communication cable Type SC NC |
| CHJPJP90/SC/NC: | Cross-Inked polyethylene insulated pair twisted individual screencros-Inked polyolefi inner sheathed stel wire braided armored marine communicafion cable Type SC NC |
| CHJ85/SC/NC: | Cross-inked polyethylene insulated copper wire braided armored cross-inked polyolefin outer sheathed marine communication cable |
| CHJP85/SC/NC: | Cros linked polyethylen islatedpair twisted idvidual scren coper wire braided armored cros-Iinked polyolefn outer sheathed marne communication cable |
| CHJPJ85/SC/NC: | XLPE insulated croslinked poyolefininne sheathed cope wire braded amoning roslinked oyolefi outer sheated manine comunictoncable |
| CHJPJP85/SC/NC: | XLPE islated pr wistedindida scren cos-nked poycefinimnershathed oper we braded rmoing uos-Inked poyolefi outershesthe main commuicationcble |
| CHJPJ95/SC/NC: | XLPEinsulated cToss-Inked polyolefin inner sheathed stel wire braided armoning coss-Inked poyolefin outer sheathed manne communication cable |
| CHJPJP95/SC/NC: | XLPE islated pa twstelindidua scren cos-Iikedpobolfi ime shath ste wie brade armurn crs-Inked poydefi nutershathe manine comunicaton cabe SCNC type |
| CHJPF/SC/NC: | XLPE insulated polyolefin outer sheathed marine communication cable SC NC type |
| CHJPFP/SC/NC: | XLPE insulated pair twisted individual screen polyolefin outer sheathed marine communication cable SC NC type |
| CHJPF80/SC/NC: | XLPEinsulated polyolefin inner sheath copper wire braided armoring marine communication cable SC NC type |
| CHJPFP80/SC/NC: | XLPE insulated pair twisted individual screen polyolefin inner sheath copper wire braided armoring marine communication cable SCNCtype |
| CHJPF90/SC/NC: | XLPE insulated pair twisted indvidual screen polyolefininer sheath steel wire braided amoning mane communication cable SC NC type |
| CHJPFP90/SC/NC: | XLPE insulated pai twisted indvidual screen polyolefininer sheath stel wire braided armoring marine communication cable SC NC type |
| CHJ86/SC/NC: | XLPE insulated copper wire braided armoring polyolefin outer sheathed marine communication cable SC NC type |
| CHJP86/SC/NC: | XLPE insulated ai twisted individual screen copper wire braided armoring polyolefin sheathed marine communication cable SC NC type |
| CHJPF86/SC/NC: | XLPE insulated polyolefin inner sheathed copper wire braided amoring polyolefin outer sheathed manne communication cable SC NC type |
| CHJPFP86/SC/NC: | XLPEinsulation pir twise indidal scren pobydefn ne sheathed oper wie braided armoingpodyolefi outer sheathe main ommunication cable SCNC type |
| CHJPF96/SC/NC: | XLPE insulated polyolefin inner sheathed wire braided amoring polyolefin outer sheathed manine communication cable SCNC type |
| CHJPFP96/SC/NC: | XLPEislated ar twsedindvidual sreen pdyolefininersheathed wire braided amoing polyolefi outer shathed marine communication cable SCNC type |
This product is suitable for signal transmission and control systems in telecommunications,electronic computers and information processing equipment.
| Crosslinked Polyethylene Insulated Marine Communication Cable at Rated Voltage of 150/250V | ||||||
| No.of cores xsectional area |
CHJVP/DA/SA,CHJPJP/SC,CHJPFP/SC | CHJVP/NA,CHJPJP/NC,CHJPFP/NC | ||||
| Over diam.mm | Approx. weight |
Over diam.mm | Approx. weight |
|||
| No. ×mm² | Nom. | Max | Nom. | Max | ||
| 1*2*0.5 | 6.5 | 9.1 | 51 | 7.5 | 10.1 | 59 |
| 2*2*0.5 | 9.6 | 12.9 | 145 | 11.6 | 14.9 | 208 |
| 3*2*0.5 | 10.4 | 13.7 | 163 | 12.3 | 15.7 | 225 |
| 4*2*0.5 | 11.3 | 14.8 | 200 | 13.6 | 17.2 | 265 |
| 5*2*0.5 | 12.3 | 16.0 | 237 | 14.9 | 18.7 | 325 |
| 7*2*0.5 | 13.5 | 17.5 | 282 | 16.2 | 20.2 | 361 |
| 10*2*0.5 | 17.2 | 21.9 | 407 | 21.0 | 25.7 | 543 |
| 12*2*0.5 | 17.8 | 22.6 | 448 | 21.7 | 26.5 | 601 |
| 14*2*0.5 | 18.7 | 23.7 | 512 | 22.9 | 27.8 | 669 |
| 16*2*0.5 | 19.7 | 24.9 | 573 | 24.3 | 29.5 | 767 |
| 19*2*0.5 | 21.0 | 26.4 | 643 | 25.7 | 31.1 | 827 |
| 24*2*0.5 | 24.7 | 30.8 | 815 | 30.5 | 36.6 | 1069 |
| 27*2*0.5 | 25.2 | 31.4 | 918 | 31.1 | 37.4 | 1198 |
| 30*2*0.5 | 26.1 | 32.5 | 1010 | 32.3 | 38.7 | 1311 |
| 33*2*0.5 | 27.3 | 33.9 | 1075 | 33.7 | 40.4 | 1418 |
| 37*2*0.5 | 28.4 | 35.2 | 1149 | 35.1 | 41.9 | 1478 |
| 1*2*0.75 | 7.3 | 9.9 | 63 | 8.3 | 10.9 | 73 |
| 2*2*0.75 | 11.3 | 14.5 | 192 | 13.1 | 16.3 | 260 |
| 3*2*0.75 | 11.9 | 15.3 | 217 | 14.1 | 17.4 | 291 |
| 4*2*0.75 | 13.0 | 16.5 | 258 | 15.4 | 18.9 | 344 |
| 5*2*0.75 | 14.4 | 18.2 | 317 | 17.1 | 20.8 | 422 |
| 7*2*0.75 | 15.7 | 19.7 | 367 | 18.6 | 22.6 | 469 |
| 10*2*0.75 | 20.3 | 25.0 | 546 | 24.1 | 28.8 | 706 |
| 12*2*0.75 | 21.0 | 25.8 | 615 | 24.9 | 29.7 | 781 |
| 14*2*0.75 | 22.1 | 27.0 | 688 | 26.4 | 31.4 | 871 |
| 16*2*0.75 | 23.5 | 28.7 | 786 | 27.9 | 33.1 | 998 |
| 19*2*0.75 | 24.8 | 30.2 | 866 | 29.7 | 35.1 | 1097 |
| 24*2*0.75 | 29.4 | 35.5 | 1116 | 35.0 | 41.1 | 1414 |
| 27*2*0.75 | 30.0 | 36.3 | 1254 | 36.0 | 42.2 | 1581 |
| 30*2*0.75 | 31.1 | 37.5 | 1377 | 37.3 | 43.7 | 1729 |
| 33*2*0.75 | 32.5 | 39.2 | 1474 | 38.8 | 45.4 | 1878 |
| 37*2*0.75 | 33.8 | 40.7 | 1573 | 40.5 | 47.4 | 1955 |
| 1*2*1 | 7.7 | 10.3 | 75 | 8.7 | 11.3 | 90 |
| 2*2*1 | 12.0 | 15.2 | 225 | 14.0 | 17.2 | 307 |
| 3*2*1 | 12.7 | 16.0 | 258 | 14.8 | 18.2 | 338 |
| 4*2*1 | 14.1 | 17.6 | 320 | 16.3 | 19.8 | 404 |
| 5*2*1 | 15.4 | 19.1 | 382 | 18.0 | 21.8 | 496 |
| 7*2*1 | 17.0 | 20.9 | 460 | 19.7 | 23.6 | 572 |
| 10*2*1 | 21.8 | 26.4 | 680 | 25.6 | 30.2 | 854 |
| 12*2*1 | 22.5 | 27.3 | 756 | 26.6 | 31.4 | 934 |
| 14*2*1 | 23.9 | 28.8 | 865 | 28.0 | 33.0 | 1064 |
| 16*2*1 | 25.2 | 30.4 | 972 | 29.8 | 35.0 | 1218 |
| 19*2*1 | 26.8 | 32.2 | 1095 | 31.5 | 36.9 | 1326 |
| 24*2*1 | 31.5 | 37.7 | 1406 | 37.3 | 43.5 | 1729 |
| 27*2*1 | 32.2 | 38.5 | 1579 | 38.2 | 44.4 | 1933 |
| 30*2*1 | 33.6 | 40.1 | 1736 | 39.8 | 46.2 | 2115 |
| 33*2*1 | 35.0 | 41.6 | 1865 | 41.4 | 48.0 | 2303 |
| 37*2*1 | 36.5 | 43.4 | 1998 | 43.2 | 50.1 | 2412 |
| 1*2*1.5 | 8.7 | 11.3 | 98 | 9.7 | 12.3 | 109 |
| 2*2*1.5 | 14.0 | 17.2 | 294 | 15.8 | 19.0 | 385 |
| 3*2*1.5 | 14.8 | 18.2 | 338 | 17.0 | 20.3 | 434 |
| 4*2*1.5 | 16.5 | 20.0 | 418 | 18.6 | 22.2 | 519 |
| 5*2*1.5 | 18.0 | 21.8 | 501 | 20.7 | 24.4 | 638 |
| 7*2*1.5 | 19.9 | 23.8 | 602 | 22.8 | 26.7 | 733 |
| 10*2*1.5 | 25.8 | 30.4 | 889 | 29.6 | 34.2 | 1096 |
| 12*2*1.5 | 26.6 | 31.4 | 1005 | 30.5 | 35.3 | 1218 |
| 14*2*1.5 | 28.0 | 33.0 | 1131 | 32.4 | 37.4 | 1385 |
| 16*2*1.5 | 29.8 | 35.0 | 1291 | 34.2 | 39.4 | 1564 |
| 19*2*1.5 | 31.5 | 36.9 | 1452 | 36.4 | 41.8 | 1725 |
| 24*2*1.5 | 37.3 | 43.5 | 1860 | 43.1 | 49.3 | 2240 |
| 27*2*1.5 | 38.4 | 44.6 | 2086 | 44.1 | 50.4 | 2502 |
| 30*2*1.5 | 39.8 | 46.2 | 2290 | 46.0 | 52.4 | 2736 |
| 33*2*1.5 | 41.6 | 48.2 | 2496 | 48.0 | 54.6 | 3018 |
| 37*2*1.5 | 43.2 | 50.1 | 2640 | 49.9 | 56.8 | 3125 |
| 1*2*2.5 | 9.5 | 12.1 | 122 | 10.7 | 13.3 | 134 |
| 2*2*2.5 | 15.4 | 18.7 | 365 | 17.4 | 20.7 | 480 |
| 3*2*2.5 | 16.6 | 19.9 | 436 | 18.5 | 21.9 | 536 |
| 4*2*2.5 | 18.2 | 21.7 | 530 | 20.6 | 24.1 | 658 |
| 5*2*2.5 | 20.2 | 23.9 | 650 | 22.8 | 26.5 | 808 |
| 7*2*2.5 | 22.2 | 26.2 | 788 | 24.9 | 28.9 | 938 |
| 10*2*2.5 | 28.8 | 33.5 | 1160 | 32.6 | 37.3 | 1416 |
| 12*2*2.5 | 29.8 | 34.6 | 1318 | 33.7 | 38.5 | 1560 |
| 14*2*2.5 | 31.6 | 36.6 | 1487 | 35.8 | 40.8 | 1776 |
| 16*2*2.5 | 33.4 | 38.6 | 1698 | 38.0 | 43.2 | 2031 |
| 19*2*2.5 | 35.5 | 40.9 | 1916 | 40.2 | 45.6 | 2225 |
| 24*2*2.5 | 42.1 | 48.2 | 2475 | 47.9 | 54.0 | 2880 |
| 27*2*2.5 | 43.0 | 49.2 | 2774 | 49.0 | 55.2 | 3246 |
| 30*2*2.5 | 44.8 | 51.2 | 3045 | 51.0 | 57.4 | 3551 |
| 33*2*2.5 | 46.8 | 53.4 | 3296 | 53.2 | 59.9 | 3890 |
| 37*2*2.5 | 48.7 | 55.5 | 3532 | 55.4 | 62.2 | 4082 |
| Note: Data above only for reference.confirmation needed by our technical department. We reserve the right to alter all information without notice. | ||||||
