| Brand Name: | JIANGNAN CABLE |
| Model Number: | CHJVP82/DASA、CHJPJP85/SC、CHJPFP86/SC CHJVP92/DASA、CHJPJP95/SC、CHJPFP96/SC CHJVP82/NA、CHJPJP85/NC、CHJPFP86/NC CHJVP92/NA、CHJPJP95/NC、CHJPFP96/NC |
| MOQ: | 100 Meter |
| Price: | US$1.00~US$20.00 |
| Payment Terms: | T/T |
| CHJV/DA/SA/NA: | XLPE insulated PVC sheathed marine communication cable DA SA NA type |
| CHJVP/DA/SA/NA: | XLPE insulated pair twisted individual screen polyvinyl chloride sheathed marine communication cable DA SA NA type |
| CHJV80/DASA/NA: | XLPE insulated polyvinyl chloride inner sheathed copper wire braided armoring communication cable for marine type DA SANA |
| CHJVP80/DAVSA/NA: | XLPEinsulated pai twisted individual screen polyviny choride inner sheathed copper wire braided amored for marine communication cable type DASA NA |
| CHJV90/DA/SA/NA: | XLPE insulated polyvinyl chloride inner sheathed steel wire braided armored communication cable for marine type DA SA NA |
| CHJVP90/DA/SA/NA: | XLPE insulated pai twisted indvidual screen polyviny chorideinner sheathed stel wre braided armored for marine communiction cable type DASA NA |
| CHJ82/DA/SA/NA: | XLPE insulated copper wire braided armoring PVC sheathed marine communication cable DA SA NA type |
| CHJV82/DASA/NA: | XLPE insulated PVCinner sheathed copper wire braided armoring PVC outer sheathed marine communication cable DA SA NA type |
| CHJP82/DASA/NA: | XLPE insulated pair twisted individual screen copper wire braided armoring PVC sheathed marine communication cable DA SANA type |
| CHJVP82/DASA/NA: | XLPE insulated twisted individual screen PVCinner sheathed copper wire braided amoning PVC outer sheathed marine communication cable |
| CHJV92/DASA/NA: | XLPE insulated PVCinner sheathed wire braided armoring PVC outer sheathed Marine communication cable DASA NA type |
| CHJVP92/DA/SA/NA: | XLPEinsulated pair twisted individual screen PVC inner sheathed wire braided armoring PVCouter sheathed marine communication cable DASA NA type |
| CHJPJ/SC/NC: | XLPE insulated crosslinked polyolefin outer sheathed marine communication cable SC NC type |
| CHJPJP/SC/NC: | Cross-Iinked polyethylene insulated pai twisted individual screen cross-linked polyolefin outer sheathed marine communication cable |
| CHJPJ80/SC/NC: | Cross-lnked polethylene inslated pai twisted individual screen cros-lnked polyolefininner sheathed copper wire braided armored marine communication cable |
| CHJPJP80/SC/NC: | CrosS-linked polyethylene insulated pair twisted indvidual scren cross-Inked polyolefn inne sheathe operwie braided armored marine commuicafion cable |
| CHJPJ90/SC/NC: | Cross-inked polyethylene insulated cross-linked polyolefin inner sheathed steel wire braided armored marine communication cable Type SC NC |
| CHJPJP90/SC/NC: | Cross-Inked polyethylene insulated pair twisted individual screencros-Inked polyolefi inner sheathed stel wire braided armored marine communicafion cable Type SC NC |
| CHJ85/SC/NC: | Cross-inked polyethylene insulated copper wire braided armored cross-inked polyolefin outer sheathed marine communication cable |
| CHJP85/SC/NC: | Cros linked polyethylen islatedpair twisted idvidual scren coper wire braided armored cros-Iinked polyolefn outer sheathed marne communication cable |
| CHJPJ85/SC/NC: | XLPE insulated croslinked poyolefininne sheathed cope wire braded amoning roslinked oyolefi outer sheated manine comunictoncable |
| CHJPJP85/SC/NC: | XLPE islated pr wistedindida scren cos-nked poycefinimnershathed oper we braded rmoing uos-Inked poyolefi outershesthe main commuicationcble |
| CHJPJ95/SC/NC: | XLPEinsulated cToss-Inked polyolefin inner sheathed stel wire braided armoning coss-Inked poyolefin outer sheathed manne communication cable |
| CHJPJP95/SC/NC: | XLPE islated pa twstelindidua scren cos-Iikedpobolfi ime shath ste wie brade armurn crs-Inked poydefi nutershathe manine comunicaton cabe SCNC type |
| CHJPF/SC/NC: | XLPE insulated polyolefin outer sheathed marine communication cable SC NC type |
| CHJPFP/SC/NC: | XLPE insulated pair twisted individual screen polyolefin outer sheathed marine communication cable SC NC type |
| CHJPF80/SC/NC: | XLPEinsulated polyolefin inner sheath copper wire braided armoring marine communication cable SC NC type |
| CHJPFP80/SC/NC: | XLPE insulated pair twisted individual screen polyolefin inner sheath copper wire braided armoring marine communication cable SCNCtype |
| CHJPF90/SC/NC: | XLPE insulated pair twisted indvidual screen polyolefininer sheath steel wire braided amoning mane communication cable SC NC type |
| CHJPFP90/SC/NC: | XLPE insulated pai twisted indvidual screen polyolefininer sheath stel wire braided armoring marine communication cable SC NC type |
| CHJ86/SC/NC: | XLPE insulated copper wire braided armoring polyolefin outer sheathed marine communication cable SC NC type |
| CHJP86/SC/NC: | XLPE insulated ai twisted individual screen copper wire braided armoring polyolefin sheathed marine communication cable SC NC type |
| CHJPF86/SC/NC: | XLPE insulated polyolefin inner sheathed copper wire braided amoring polyolefin outer sheathed manne communication cable SC NC type |
| CHJPFP86/SC/NC: | XLPEinsulation pir twise indidal scren pobydefn ne sheathed oper wie braided armoingpodyolefi outer sheathe main ommunication cable SCNC type |
| CHJPF96/SC/NC: | XLPE insulated polyolefin inner sheathed wire braided amoring polyolefin outer sheathed manine communication cable SCNC type |
| CHJPFP96/SC/NC: | XLPEislated ar twsedindvidual sreen pdyolefininersheathed wire braided amoing polyolefi outer shathed marine communication cable SCNC type |
This product is suitable for signal transmission and control systems in telecommunications,electronic computers and information processing equipment.
| Crosslinked Polyethylene Insulated Marine Communication Cable at Rated Voltage of 150/250V | ||||||||
| No.of cores xsectional area |
CHJVP82/DASA,CHJPJP85/SC,CHJPFP86/SC CHJVP92/DASA,CHJPJP95/SC,CHJPFP96/SC |
CHJVP82/NA,CHJPJP85/NC,CHJPFP86/NC CHJVP92/NA,CHJPJP95/NC,CHJPFP96/NC |
||||||
| Over diam.mm | Approx.weight | Over diam.mm | Approx.weight | |||||
| No. ×mm² | Nom. | Max | TYPE 82/85/86 | TYPE 92/95/96 | Nom. | Max | TYPE 82/85/86 | TYPE 92/95/96 |
| 1*2*0.5 | 8.9 | 12.3 | 107 | 105 | 9.9 | 13.3 | 122 | 119 |
| 2*2*0.5 | 12.0 | 16.1 | 241 | 237 | 14.2 | 18.3 | 327 | 322 |
| 3*2*0.5 | 12.8 | 16.9 | 264 | 260 | 14.9 | 19.1 | 351 | 345 |
| 4*2*0.5 | 13.9 | 18.2 | 320 | 315 | 16.2 | 20.6 | 394 | 407 |
| 5*2*0.5 | 14.9 | 19.4 | 378 | 371 | 17.5 | 22.1 | 512 | 501 |
| 7*2*0.5 | 16.1 | 20.9 | 437 | 429 | 19.0 | 23.8 | 574 | 563 |
| 10*2*0.5 | 20.6 | 26.1 | 642 | 629 | 25.0 | 30.5 | 861 | 846 |
| 12*2*0.5 | 21.2 | 26.8 | 718 | 705 | 25.7 | 31.3 | 932 | 916 |
| 14*2*0.5 | 22.1 | 27.9 | 811 | 797 | 26.9 | 32.6 | 1067 | 1047 |
| 16*2*0.5 | 23.1 | 29.1 | 886 | 872 | 28.1 | 34.1 | 1151 | 1166 |
| 19*2*0.5 | 25.0 | 31.2 | 975 | 960 | 29.7 | 35.9 | 1269 | 1246 |
| 24*2*0.5 | 28.7 | 35.6 | 1259 | 1236 | 34.5 | 41.4 | 1590 | 1603 |
| 27*2*0.5 | 29.2 | 36.2 | 1420 | 1394 | 35.1 | 42.2 | 1830 | 1800 |
| 30*2*0.5 | 30.1 | 37.3 | 1553 | 1527 | 36.3 | 43.5 | 1970 | 1939 |
| 33*2*0.5 | 31.1 | 38.5 | 1583 | 1557 | 37.7 | 45.2 | 2058 | 2027 |
| 37*2*0.5 | 32.2 | 39.8 | 1699 | 1672 | 39.3 | 46.9 | 2145 | 2113 |
| 1*2*0.75 | 9.7 | 13.1 | 126 | 123 | 10.7 | 14.1 | 142 | 139 |
| 2*2*0.75 | 13.9 | 17.9 | 310 | 305 | 15.7 | 19.7 | 375 | 397 |
| 3*2*0.75 | 14.5 | 18.7 | 342 | 336 | 16.7 | 20.8 | 445 | 438 |
| 4*2*0.75 | 15.6 | 19.9 | 407 | 399 | 18.2 | 22.5 | 547 | 536 |
| 5*2*0.75 | 17.0 | 21.6 | 479 | 471 | 19.9 | 24.4 | 644 | 632 |
| 7*2*0.75 | 18.5 | 23.3 | 580 | 568 | 22.0 | 26.8 | 715 | 725 |
| 10*2*0.75 | 23.9 | 29.4 | 862 | 847 | 27.9 | 33.4 | 1076 | 1097 |
| 12*2*0.75 | 25.0 | 30.6 | 944 | 928 | 28.9 | 34.5 | 1210 | 1188 |
| 14*2*0.75 | 26.1 | 31.8 | 1049 | 1032 | 30.2 | 36.0 | 1321 | 1298 |
| 16*2*0.75 | 27.3 | 33.3 | 1205 | 1183 | 31.7 | 37.7 | 1493 | 1468 |
| 19*2*0.75 | 28.8 | 35.0 | 1306 | 1283 | 33.7 | 39.9 | 1641 | 1614 |
| 24*2*0.75 | 33.4 | 40.3 | 1673 | 1646 | 39.2 | 46.1 | 2075 | 2044 |
| 27*2*0.75 | 34.0 | 41.1 | 1859 | 1830 | 40.2 | 47.2 | 2326 | 2292 |
| 30*2*0.75 | 35.1 | 42.3 | 2032 | 2001 | 41.5 | 48.7 | 2566 | 2523 |
| 33*2*0.75 | 36.5 | 44.0 | 2110 | 2080 | 43.2 | 50.6 | 2691 | 2649 |
| 37*2*0.75 | 37.8 | 45.5 | 2235 | 2204 | 44.9 | 52.6 | 2803 | 2760 |
| 1*2*1 | 10.1 | 13.5 | 141 | 137 | 11.1 | 14.5 | 170 | 167 |
| 2*2*1 | 14.6 | 18.6 | 349 | 344 | 16.6 | 20.6 | 460 | 452 |
| 3*2*1 | 15.3 | 19.4 | 402 | 395 | 17.4 | 21.6 | 500 | 492 |
| 4*2*1 | 16.7 | 21.0 | 478 | 470 | 19.1 | 23.4 | 616 | 605 |
| 5*2*1 | 18.2 | 22.7 | 590 | 578 | 21.4 | 26.0 | 729 | 717 |
| 7*2*1 | 20.4 | 25.1 | 688 | 675 | 23.1 | 27.8 | 871 | 857 |
| 10*2*1 | 25.8 | 31.2 | 1018 | 1002 | 29.6 | 35.0 | 1292 | 1269 |
| 12*2*1 | 26.5 | 32.1 | 1157 | 1136 | 30.4 | 36.0 | 1386 | 1362 |
| 14*2*1 | 27.7 | 33.4 | 1288 | 1266 | 31.8 | 37.6 | 1561 | 1535 |
| 16*2*1 | 29.2 | 35.2 | 1416 | 1393 | 33.8 | 39.8 | 1763 | 1737 |
| 19*2*1 | 30.6 | 36.8 | 1584 | 1560 | 35.5 | 41.7 | 1900 | 1872 |
| 24*2*1 | 35.5 | 42.5 | 2002 | 1973 | 41.5 | 48.5 | 2456 | 2422 |
| 27*2*1 | 36.2 | 43.3 | 2251 | 2219 | 42.4 | 49.4 | 2785 | 2741 |
| 30*2*1 | 37.6 | 44.9 | 2461 | 2428 | 44.2 | 51.4 | 3032 | 2986 |
| 33*2*1 | 39.2 | 46.6 | 2545 | 2513 | 45.8 | 53.2 | 3194 | 3149 |
| 37*2*1 | 40.7 | 48.4 | 2733 | 2699 | 47.8 | 55.5 | 3340 | 3294 |
| 1*2*1.5 | 11.1 | 14.5 | 179 | 176 | 12.1 | 15.5 | 198 | 194 |
| 2*2*1.5 | 16.6 | 20.6 | 450 | 442 | 18.6 | 22.6 | 591 | 579 |
| 3*2*1.5 | 17.6 | 21.8 | 537 | 526 | 19.8 | 23.9 | 618 | 643 |
| 4*2*1.5 | 19.3 | 23.6 | 637 | 625 | 22.0 | 26.4 | 788 | 774 |
| 5*2*1.5 | 21.4 | 26.0 | 739 | 726 | 24.3 | 28.8 | 896 | 932 |
| 7*2*1.5 | 23.5 | 28.2 | 907 | 892 | 26.6 | 31.3 | 1071 | 1055 |
| 10*2*1.5 | 29.6 | 35.0 | 1335 | 1312 | 33.6 | 39.0 | 1611 | 1585 |
| 12*2*1.5 | 30.4 | 36.0 | 1488 | 1464 | 34.5 | 40.1 | 1718 | 1747 |
| 14*2*1.5 | 31.8 | 37.6 | 1638 | 1612 | 36.4 | 42.2 | 2194 | 1944 |
| 16*2*1.5 | 33.8 | 39.8 | 1848 | 1820 | 38.4 | 44.4 | 1973 | 2174 |
| 19*2*1.5 | 35.5 | 41.7 | 2040 | 2012 | 40.6 | 46.8 | 2205 | 2370 |
| 24*2*1.5 | 41.7 | 48.7 | 2602 | 2567 | 47.7 | 54.7 | 2403 | 3116 |
| 27*2*1.5 | 42.8 | 49.8 | 2984 | 2939 | 48.7 | 55.8 | 3162 | 3485 |
| 30*2*1.5 | 44.2 | 51.4 | 3226 | 3179 | 50.6 | 57.8 | 3536 | 3793 |
| 33*2*1.5 | 46.0 | 53.4 | 3409 | 3363 | 52.8 | 60.2 | 3846 | 4018 |
| 37*2*1.5 | 47.8 | 55.5 | 3588 | 3540 | 55.1 | 62.8 | 4069 | 4195 |
| 1*2*2.5 | 11.9 | 15.3 | 210 | 206 | 13.3 | 16.7 | 230 | 225 |
| 2*2*2.5 | 18.2 | 22.3 | 570 | 559 | 20.2 | 24.3 | 705 | 693 |
| 3*2*2.5 | 19.4 | 23.5 | 655 | 643 | 21.9 | 26.1 | 774 | 761 |
| 4*2*2.5 | 21.6 | 25.9 | 769 | 756 | 24.2 | 28.5 | 965 | 951 |
| 5*2*2.5 | 23.8 | 28.3 | 958 | 943 | 26.6 | 31.1 | 1146 | 1130 |
| 7*2*2.5 | 26.0 | 30.8 | 1124 | 1108 | 28.9 | 33.7 | 1363 | 1340 |
| 10*2*2.5 | 32.8 | 38.3 | 1673 | 1647 | 36.6 | 42.1 | 2005 | 1976 |
| 12*2*2.5 | 33.8 | 39.4 | 1872 | 1845 | 37.9 | 43.5 | 2191 | 2161 |
| 14*2*2.5 | 35.6 | 41.4 | 2069 | 2041 | 40.0 | 45.8 | 2443 | 2411 |
| 16*2*2.5 | 37.6 | 43.6 | 2336 | 2306 | 42.4 | 48.4 | 2762 | 2728 |
| 19*2*2.5 | 39.7 | 45.9 | 2591 | 2559 | 44.6 | 50.8 | 3054 | 3011 |
| 24*2*2.5 | 46.7 | 53.6 | 3392 | 3347 | 52.7 | 59.6 | 3921 | 3870 |
| 27*2*2.5 | 47.6 | 54.6 | 3803 | 3753 | 53.8 | 60.8 | 4417 | 4362 |
| 30*2*2.5 | 49.4 | 56.6 | 4150 | 4098 | 56.4 | 63.6 | 4970 | 4893 |
| 33*2*2.5 | 51.6 | 59.0 | 4339 | 4288 | 58.6 | 66.1 | 5234 | 5159 |
| 37*2*2.5 | 53.9 | 61.5 | 4651 | 4598 | 61.0 | 68.6 | 5518 | 5440 |
| Note: Data above only for reference.confirmation needed by our technical department. We reserve the right to alter all information without notice. | ||||||||
