Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle

Brand Name:	ASAC
Model Number:	TO BE MENTIONED
MOQ:	10T
Price:	US$1030-3400/T
Payment Terms:	T/T
Supply Ability:	30000T/YEAR

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ABS,BV,CCS,CR,DNV,LR,NK,RINA,RMRS,KR

Products Name:

Marine Anchor Chain

Standard:

ISO9001,API-Q1/ISO14001,OHSAS18001andHSE/ISO50001

Usage:

Marine Anchoring

Surface Treatment:

Black Painted

Application:

Ship

Color:

Black Painted

Packaging Details:

Plywood pallets/Wooden Box/PP ton bag

Highlight:

Common Link Marine Shackle 12.5mm

178mm Steel Anchor Shackle

12.5mm Steel Anchor Shackle

Product Description

Common-Link Marine Anchor Chain with 12.5-178mm Size, ABS BV CCS Certificates, and Black Painted Surface for Ships

1.Production Capacity

(1) We have independently designed and manufactured an automatic production line for 26 large and medium-sized anchor chains, with 6 fully automatic continuous heat treatment lines and 4000T anchor chain tensile equipment for testing. These are used for the production of AM2 and AM3 marine anchor chains with diameters ranging from 12.5mm to 240mm, as well as R3, R3S, R4, R4S, R5 and R6 marine mooring chains. We have 7 automated forging production lines that can produce various shapes and specifications of accessories, with an annual output of nearly 30,000 tons. Among them, the 2500T hydraulic machine can produce accessories weighing up to 16T. The 8T die forging production line can produce marine engineering accessories weighing over 6T and with specifications over 240mm, which is at the world's leading level. We can also accept various non-standard product customization to meet the needs of different customers.

(2) Equipment List

Various sizes of chain units:3, 5,6,7,8,9,11, 16total 39 sets

Automatic chain heat treatment furnace: I5 sets

Automatic chain proof test machine:

2000/5000/12000/24000/40000kN total10 sets

Chain shot blasting machine: 8 sets

Bending/shaping machine: 6 sets

Heating furnace: 10 sets

Batch furnace(gas) and electric furnace: I5 sets

Machining equipment: 29 sets

Various types of cranes, big truck crane etc. 30t I5 sets

150 meters deep-water pier: I

Other equipments: over 300 sets

Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle 0

Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle 4

Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle 6

Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle 8

Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle 12

2. Manufacturing Progress of Anchor Chain

Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle 13

3. Quality Inspection Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle 15

Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle 16

Common Link Marine Shackle 12.5mm-178mm Size Steel Anchor Shackle 18

4. Product Grade and Mechanical Properties

Grade/Size/Certificate of Anchor chain & Accessories
Product	Stud anchor chain	Studless anchor chain	Anchor Chain Accessories
Grade	M2,M3	M2,M3	M2,M3
Size	12.5-178mm	12.5-178mm	152mm
Certificate	ABS,BV,CCS,CR,DNV,LR,NK,RINA,RMRS		ABS,BV,CCS,CR,DNV,KR,LR,NK,RINA,RMRS

Mechanical Properties of Anchor Chain
Grade	Yield Point (N/mm²,min)	Tensile Strength (N/mm²,min)	Elongation (%,min)	Reduction Of Area (%,min)	Charpy V-notch
					Test Temperature (℃)	Impact(J,min)
2	≥295	490~690	≥22	---	0	≥27
3	≥410	≥690	≥17	≥40	0	≥60
						≥50(weld)
4	≥490	≥770	≥12	≥50	-20	≥45
						≥33(weld)

5.Weight

Weight(KG)
Chain Diameter (mm)	Stud Link Chain kg/27.5m	Common Link	Enlarged Link	End Link	Kenter Shackle	Joining Shackle	End Shackle	Swivel	Anchor Swivel Shackle A.SW.S(a)	Anchor Swivel Shackle A.SW.S(b)
12.5	105	0.19	0.26	0.26	0.45	0.48	1.1	0.8	6.4	1.8
14	142	0.26	0.39	0.32	0.6	0.67	1.5	1.05	9	2.5
16	175	0.35	0.49	0.57	0.65	0.95	1.52	1.34	14	3.2
17.5	197	0.50	0.66	0.67	0.88	1.34	2.05	1.73	14	4.9
19	245	0.66	0.85	1.06	1.13	1.84	2.41	2.17	17	6.3
20.5	268	0.80	1.02	1.06	1.36	2.2	3.25	2.2	17	7.9
22	324	1.04	1.30	1.58	1.64	2.66	3.95	3.5	22	9.8
24	370	1.30	1.65	1.84	2.13	3.4	5.12	4.53	22	12.8
26	431	1.64	2.03	2.74	2.58	4.5	6.7	5.79	43	16.2
28	496	2.04	2.48	3.23	3.3	5.19	8.1	7.25	43	20.3
30	563	2.48	3.58	3.74	4.15	6.32	10	9	98	24.9
32	635	2.98	4.45	4.74	5.06	8.24	11.77	10.03	98	30.2
34	712	3.54	5.21	5.54	6.01	9.56	14.2	12.75	118	36.3
36	800	4.23	5.99	6.95	6.89	11.31	16.55	14.96		43.1
38	888	4.96	6.15	7.66	8.4	13.45	19.55	17.44		51
40	1033	6.04	8.01	8.2	9.63	15.5	22.8	20.25	128	59
42	1084	6.65	9.04	9.92	\| Ⅱ	18.1	26	25.4	128	68
44	1197	7.73	10.25	11.42	12.45	20.25	29.71	26.6	160	79
46	1310	8.80	11.54	13.92	14.1	23.33	34.3	30.67		90
48	1438	10.06	14.44	15.67	16.7	27.5	38.0	35.0		102
50	1546	11.28	16.06	17.7	19.0	31.6	45.2	40.5	289	115
52	1661	12.68	17.85	18.97	20.3	34.0	50.9	49.5	289	130
54	1791	14.10	19.60	20.84	23.7	38.5	53.8	50.5	300	145
56	1926	15.66	21.69	23.55	26.7	46.0	63.0	55.0	300	162
58	2086	17.83	24.0	25.95	27.2	46.8	70.0	64.6	330	180
60	2249	19.90	26.0	28.48	27.7	51.0	77.5	71.3		199
62	2361	21.66	28.63	30.81	35	59.2	86.3	77.7		220
64	2516	23.51	31.13	32.7	38.4	62.7	96.3	83.3	458	242
66	2676	25.98	35.0	38.4	42.3	75	99.6	88.7		265
68	2885	28.60	39.72	39.5	46.0	76.7	102.6	100.0		290
70	3010	31.00	43.33	43.8	48.7	90	126.2	107.8	522	317
73	3274	35.20	48.30	49	53.0	95	138.2	125.6	522	359
76	3548	39.90	53.6	57.1	60.7	107	146	143.8	522	405
78	3737	43.00	59.6	62.3	65.5	116	164	154	815	438
81	4030	48.60	66.0	67.4	75	130	190	188	815	491
84	4334	53.50	69.0	74.4	90	136	212	198	1007	547
87	4650	58.90	81.1	84.6	96	160	237	215	1007	608
90	4976	66.35	88.0	91	108	176	245	238	1300	673
92	5199	71.22	97.5	100	114	196	257	252		781
95	5544	78.08	101	109	128	215	300	269		833
97	5780	83.77	107	117	133	222	335	301	1610	842
100	6143	89.03	120	127	146	252	353	330		923
102	6398	95.50	130	134	158	267	378	344		980
105	6773	104.20	139	150	160	294	385	387	1827	1069
107	7033	I11.63	148	160	180	305	420	428	1827	1131
I11	7569	124.08	161	171	198	325	463	448	2022	1262
114	7983	135.31	168	190	204	345	485	460		1368
117	8409	147.53	177	209	225	365	528	475		1478
120	8863	155.49	204	229	250	400	570	547	2336	1595
122	9143	166.24	218	234	263	425	602	649	2336	1676
124	9399	170.90	228	246	290	465	632	680	2636	1760
127	9830	185.47	244	269	312	499	679	729	2636	1891
130	10300	194.34	264	293	333	536	729	784	2960	2028
132	10620	208.24	270	298	350	561	762	820		2123
137	11439	233.45	298	329	392	627	852	912	3309	2374
142	12289	261.47	333	383	436	698	949	1012	3685	2643
147	13170	297.67	377	419	485	774	1053	1124	4088	2932
152	14081	312.91	416	458	537	856	1164	1238	4520	3242
157	15023	349.37	450	499	591	943	1283	1360	4980	3572
162	15995	390.12	496	542	651	1036	1410	1490	5470	3925

6. Testing Load Of Anchor Chain And Accessories

Testing Load Of Anchor Chain And Accessories (MS Units)
Diameter of Chain (mm)	Grade 2			Grade 3
	Tensile load PL	Breaking load BL		Tensile load PL		Breaking load BL
	KN	KN		KN		KN
12.5	66	92		92		132
14	82	116		116		165
16	107	150		150		216
17.5	127	179		179		256
19	150	211		211		301
20.5	175	244		244		349
22	200	280		280		401
24	237	332		332		476
26	278	389		389		556
28	321	449		449		642
30	368	514		514		735
32	417	583		583		833
34	468	655		655		937
36	523	732		732		1050
38	581	812		812		1160
40	640	896		896		1280
42	703	981		981		1400
44	769	1080		1080		1540
46	837	1170		1170		1680
48	908	1270		1270		1810
50	981	1370		370		1960
52	1060	1480		1480		2110
54	1140	1590		1590		2270
56	1220	1710		1710		2430
58	1290	1810		1810		2600
60	1380	1940		1940		2770
62	1470	2060		2060		2940
64	1560	2190		2190		3130
66	1660	2310		2310		3300
68	1750	2450		2450		3500
70	1840	2580		2580		3690
73	1990	2790		2790		3990
76	2150	3010		3010		4300
78	2260	3160		3160		4500
81	2410	3380		3380		4820
84	2580	3610		3610		5160
87	2750	3850		3850		5500
90	2920	4090		4090		5840
92	3040	4260		4260		6080
95	3230	4510		4510		6440
97	3340	4680		4680		6690
100	3530	4940		4940		7060
102	3660	5120		5120		7320
105	3850	5390		5390		7700
107	3980	5570		5570		7960
111	4250	5940		5940		8480
114	4440	6230		6230		8890
117	4650	6510		6510		9300
120	4850	6810		6810		9720
22	5000	7000		7000		9990
124	5140	7200		7200		10280
127	5350	7490		7490		10710
130	5570	7800		7800		\|140
132	5720	8000		8000		11420
137	6080	8510		8510		12160
142	6450	9030		9030		12910
147	6840	9560		9560		13660
152	7220	10100		10100		14430
157	7600	10640		10640		15200
162	7990	11180		11180		15980
165	LOAD(kN)		Grade 2		Grade 3
168
171
175
178	Tensile Strength PL		0.0098ld²(44-0.08d)		0.01373d²(44-0.08d)
180
182
185
188	Breaking load BL		0.01373d²(44-0.08d)		0.01961d²(44-0.08d)
191
194
197
Mark:The real loading data shall subject to the formula calculation.

7. Joining Forms(K.S) to Anchor and Locker Ends

8. ANCHOR CHAIN ANDACCESSORIES APPROVAL CERTIFICATES
