3.6/6kV Marine Power Wire Flame Retardant XLPE Insulation Marine Electrical Wiring

Brand Name:	JIANGNAN CABLE
Model Number:	CJPJ/SC CJV/DNSA CJPJ85/SC CJPJ95/SC CJV82/DNSA CJV92/DNSA
MOQ:	100 Meter
Price:	US$1.00~US$20.00
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CCS BV

Product Name:

Marine Power Cable

Insulation Material:

Crosslinked Polyethylene

Inner Sheath Material:

Polyvinyl Chloride

Armor Type:

Galvanized Steel Wire Braid

Oversheath Type:

PVC Outer Sheath

Combustion Characteristic:

Fire- Resistant

Packaging Details:

DRUM

Highlight:

3.6/6kV Marine Power Wire

Marine Power Wire Flame Retardant

XLPE Insulation Marine Electrical Wiring

Product Description

3.6/6kV Rated Voltage Flame Retardant Marine Power Cable with 90°C Operating Temperature and XLPE Insulation

Crosslinked Polyethylene Insulated Marine Power Cable - 3.6/6kV Rated Voltage

Executive Standard

This product implements: IEC60092-354 standard.

Cable Categories and Types

CJPJ/SC: XLPE insulated crosslinked polyolefin outer sheathed Marine power cable type SC
CJV/DNSA: XLPE insulated PVC sheathed marine power cable DA/SA type
CJPJ85/SC: XLPE insulated crosslinked polyolefin inner sheath, Copper wire braided armoring, crosslinked polyolefin outer sheath marine power cable type SC
CJPJ95/SC: XLPE insulated crosslinked polyolefin inner sheathed wire braided armoring, crosslinked polyolefin outer sheathed marine power cable Type SC
CJV82/DNSA: XLPE insulated PVC inner sheathed copper wire braided armored PVC outer sheathed marine power cable DA/SA type
CJV92/DNSA: XLPE insulated PVC inner sheathed wire braided armored PVC outer sheathed marine power cable DA/SA type

Product Application

This product is suitable for electric power devices in water structures such as cabins and offshore oil platforms.

Cable Parameters

Rated voltage: 3.6/6 (7.2) kV

No. of cores x sectional area	CJPJ/SC CJV/DNSA				CJPJ85/SC CJPJ95/SC CJV82/DNSA CJV92/DNSA
No. of cores x sectional area	Over diam. mm		Approx weight		Over diam. mm		Approx weight
	Nom	Max	Type 82/85	Type 92/95	Nom	Max	Type 82/85	Type 92/95
1x10	15.1	17.3	370		17.9	20.5	571	561
1x16	16.0	18.4	446		18.8	21.6	657	646
1x25	17.6	20.2	573		20.6	23.6	815	803
1x35	18.6	21.3	689		21.6	24.8	943	931
1x50	20.0	23.0	841		23.6	27.1	1137	1124
1x70	21.6	24.8	1072		25.4	29.2	1403	1389
1x95	23.5	27.0	1364		27.5	31.6	1755	1735
1x120	24.7	28.4	1611		28.7	33.0	2020	2000
1x150	26.5	30.4	1915		30.7	35.3	2369	2347
1x185	28.3	32.5	2297		32.5	37.3	2779	2756
1x240	31.1	35.7	2898		35.5	40.8	3444	3418
1x300	33.6	38.6	3528		38.2	43.9	4135	4107
3x10	30.0	34.5	1371		34.4	39.6	1906	1881
3x16	32.2	37.0	1662		36.6	42.0	2232	2205
3x25	35.4	40.7	2114		40.0	46.0	2758	2729
3x35	37.7	43.4	2548		42.5	48.9	3255	3224
3x50	40.5	46.6	3079		45.5	52.3	3860	3827
3x70	44.2	50.8	3919		49.2	56.5	4764	4728
3x95	48.2	55.5	4952		53.4	61.4	5900	5860
3x120	51.0	58.7	5835		56.6	65.1	6937	6887
3x150	54.6	62.8	6894		60.4	69.5	8103	8049
3x185	58.5	67.3	8230		64.5	74.2	9554	9497

Note: The above are the commonly used typical voltage levels and model specifications. If you need other model voltage levels, please consult our company's technical department.

Main Technical Characteristics

The rated voltage of the cable is 3.6(7.2)kV, 6/10(12)kV, 8.7/15(17.5)kV
The allowable long-term operating temperature of the cable conductor is 90°C
The flame retardant performance of the cable conforms to IEC80332-1-2 IEC80332-3-22 standard
The fire resistance of the cable conforms to IEC80331-21 standard
The minimum bending radius of a single-core cable is 12 times the outer diameter of the cable, and the minimum bending radius of a 3-core cable is 9 times the outer diameter of the cable

Identification

The insulation core is identified by color tape
Sheath printed with factory name, type, voltage, specification, length mark, etc.

Structure Diagram
