| Brand Name: | JIANGNAN CABLE |
| Model Number: | CEF/DA/SA CEV/DA/SA CEH/DA/SA CEPJ/SC CEPF/SC CEF/NA CEV/NA CEH/NA CEPJ/NC CEPF/NC |
| MOQ: | 100 Meter |
| Price: | US$1.00~US$20.00 |
| Payment Terms: | T/T |
0.6/1kV Rated Voltage Marine Power Cable with 90°C Operating Temperature and Flame Retardant Ethylene-propylene Insulated CEF/DA/SA Cable
CEFR/DA/SA: Ethylene propylene insulated neoprene sheathed marine power flexible cable
CEFRP/DA/SA: Ethylene propylene insulated copper wire shielded neoprene outer sheathed marine power flexible cable type
CEF/DA/SA/NA: Ethylene propylene insulated neoprene sheathed marine power cable DA SA NA type
CEF80/DA/SA/NA: Ethylene propylene insulated neoprene inner sheathed copper wire braided armoring power cable for marine type
CEF90/DA/SA/NA:Ethylene propylene insulated neoprene inner sheathed steel wire braided armoring power cable for marine
CEF82/DA/SA/NA: Ethylene propylene insulated neoprene inner sheathed copper braided armouring polyvinyl chloride outer sheathed marine power cable
CEF92/DA/SA/NA: Ethylene propylene chloroprene inner sheathed wire braided armored PVC outer sheathed marine power cable
CEH/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene outer sheathed marine power cable DA SA NA type
CEH80/DA/SA/NA:
Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed copper wire braided armoring power cable for marine
CEH90/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed steel wire braided armoring power cable for marine
CEH82/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed copper wire braided armored polyvinyl chloride outer sheathed marine power cable
CEH92/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed wire braided armored polyvinyl chloride outer sheathed marine power cable
CEV/DA/SA/NA: Ethylene propylene insulated polyvinyl chloride sheathed marine power cable
CEV80/DA/SA/NA: Ethylene propylene inulatedpolnhlridennesheathedcoewirebraidedarmorsormarnepowecabldstype
CEV90/DA/SA/NA: Ethylene propylene insulated polyvinyl chloride inner sheathed steel wire braided armors for marine power cable
CEV82/DA/SA/NA: Ethylene propylene insulated PVC inner sheathed copper wire braided armored PVC outer sheathed marine power cable DA SA NA type
CEV92/DA/SA/NA: Ethylene propylene insulated PVC inner sheathed wire braided armored PVC outer sheathed marine power cable
CEPJ/SC/NC: Ethylene-propylene insulated cross-linked polyolefin outer sheathed marine power cable SC NC type
CEPJ8O/SC/NC: Ethylene propylene insulated cross-linked polyolefin inner sheathed copper wire braided armoring power cable for marine
CEPJ90/SC/NC: Ethylene-propylene insulated cross-linked polyolefin inner sheathed steel wire braided armors for marine power cable SC NC type
CEPJ85/SC/NC: Ethylene propylene insulated cross-linked polyolefin inner sheathed copper wire braided armoring cross-linked Polyolefin outer sheathed marine power cable
CEPJ95/SC/NC: Ethylene-propylene insulated cross-linked polyolefin inner sheathed wire braided armoring cross-linked polyolefin outer sheathed marine power cable
CEPF/SC/NC: Ethylene propylene insulated polyolefin outer sheathed marine power cable SC NC type
CEPF80/SC/NC: Ethylene propylene insulated polyolefin inner sheathed copper wire braided armoring for marine power cable SC NC type
| Ethylene-propylene Insulated Marine Power Cable at Rated Voltage of 0.6/1kV | ||||||
| No.of cores ×sectional area |
CEF/DA/SA CEV/DA/SA CEH/DA/SA CEPJ/SC CEPF/SC | CEF/NA CEV/NA CEH/NA CEPJ/NC CEPF/NC | ||||
| Over diam.mm | Approx. weight |
Over diam.mm | Approx. weight |
|||
| Nom. | Max | Nom. | Max | |||
| 1*1 | 5.6 | 7.0 | 49 | 6.0 | 7.4 | 55 |
| 1*1.5 | 5.9 | 7.3 | 57 | 6.3 | 7.7 | 63 |
| 1*2.5 | 6.3 | 7.7 | 70 | 6.7 | 8.1 | 76 |
| 1*4 | 6.8 | 8.2 | 89 | 7.2 | 8.6 | 96 |
| 1*6 | 7.4 | 8.8 | 113 | 7.8 | 9.2 | 120 |
| 1*10 | 8.5 | 9.9 | 171 | 8.7 | 10.1 | 174 |
| 1*16 | 9.7 | 11.1 | 237 | 9.9 | 11.3 | 240 |
| 1*25 | 11.3 | 12.7 | 352 | 11.5 | 12.9 | 354 |
| 1*35 | 12.8 | 14.2 | 449 | 13.3 | 14.7 | 457 |
| 1*50 | 14.4 | 15.8 | 623 | 15.1 | 16.6 | 630 |
| 1*70 | 16.6 | 18.2 | 841 | 17.1 | 18.7 | 849 |
| 1*95 | 19.1 | 20.7 | 1124 | 19.6 | 21.2 | 1171 |
| 1*120 | 20.6 | 22.2 | 1379 | 21.1 | 22.7 | 1409 |
| 1*150 | 22.8 | 24.4 | 1692 | 23.3 | 24.9 | 1705 |
| 1*185 | 25.3 | 27.2 | 2093 | 25.8 | 27.7 | 2107 |
| 1*240 | 28.4 | 30.3 | 2676 | 28.9 | 30.8 | 2690 |
| 1*300 | 31.8 | 34.1 | 3394 | 32.3 | 34.6 | 3409 |
| 2*1 | 9.1 | 10.7 | 114 | 9.9 | 11.5 | 131 |
| 2*1.5 | 9.9 | 11.5 | 133 | 10.7 | 12.3 | 151 |
| 2*2.5 | 10.7 | 12.3 | 164 | 11.5 | 13.1 | 189 |
| 2*4 | 11.7 | 13.3 | 214 | 12.5 | 14.1 | 235 |
| 2*6 | 13.1 | 14.7 | 272 | 13.9 | 15.5 | 324 |
| 2*10 | 15.7 | 17.4 | 454 | 16.1 | 17.8 | 458 |
| 2*16 | 17.9 | 19.7 | 642 | 18.3 | 20.1 | 648 |
| 2*25 | 21.3 | 23.1 | 925 | 21.7 | 23.5 | 927 |
| 2*35 | 24.2 | 26.0 | 1190 | 25.2 | 27.0 | 1205 |
| 2*50 | 27.8 | 29.7 | 1575 | 29.2 | 31.4 | 1655 |
| 2*70 | 32.0 | 34.3 | 2239 | 33.0 | 35.3 | 2253 |
| 2*95 | 36.9 | 39.2 | 2965 | 37.9 | 40.2 | 3018 |
| 2*120 | 40.1 | 42.5 | 3542 | 41.1 | 43.5 | 3597 |
| 3*1 | 9.8 | 11.5 | 136 | 10.7 | 12.3 | 155 |
| 3*1.5 | 10.5 | 12.1 | 160 | 11.3 | 13.0 | 186 |
| 3*2.5 | 11.3 | 13.0 | 206 | 12.2 | 13.8 | 229 |
| 3*4 | 12.6 | 14.2 | 266 | 13.5 | 15.1 | 290 |
| 3*6 | 13.9 | 15.5 | 350 | 14.9 | 16.7 | 392 |
| 3*10 | 16.9 | 18.7 | 563 | 17.3 | 19.1 | 572 |
| 3*16 | 19.2 | 21.1 | 809 | 19.7 | 21.5 | 837 |
| 3*25 | 22.9 | 24.8 | 1238 | 23.4 | 25.2 | 1243 |
| 3*35 | 26.0 | 27.9 | 1562 | 27.0 | 28.9 | 1584 |
| 3*50 | 30.0 | 32.2 | 2138 | 31.0 | 33.3 | 2188 |
| 3*70 | 34.3 | 36.7 | 2905 | 35.4 | 37.8 | 2928 |
| 3*95 | 39.5 | 42.0 | 3942 | 40.6 | 43.1 | 3979 |
| 3*120 | 43.0 | 45.5 | 4797 | 44.1 | 46.6 | 4882 |
| 3*150 | 47.6 | 50.2 | 5878 | 48.7 | 51.3 | 5928 |
| 3*185 | 53.1 | 56.2 | 7251 | 54.2 | 57.3 | 7290 |
| 4*1 | 10.7 | 12.4 | 163 | 11.7 | 13.4 | 192 |
| 5*1 | 11.4 | 13.1 | 206 | 12.5 | 14.2 | 234 |
| 7*1 | 12.8 | 14.6 | 252 | 14.0 | 15.7 | 295 |
| 10*1 | 16.5 | 18.6 | 377 | 18.0 | 20.2 | 442 |
| 12*1 | 17.0 | 19.2 | 431 | 18.6 | 20.8 | 494 |
| 14*1 | 17.8 | 20.1 | 483 | 19.6 | 21.8 | 573 |
| 16*1 | 19.0 | 21.4 | 536 | 20.8 | 23.2 | 645 |
| 19*1 | 20.0 | 22.4 | 632 | 22.0 | 24.3 | 724 |
| 24*1 | 23.5 | 26.2 | 795 | 25.9 | 28.5 | 925 |
| 27*1 | 24.3 | 26.9 | 883 | 26.7 | 29.3 | 1028 |
| 30*1 | 25.1 | 27.9 | 974 | 27.9 | 31.0 | 1133 |
| 33*1 | 26.1 | 28.9 | 1041 | 29.0 | 32.1 | 1220 |
| 37*1 | 27.3 | 30.2 | 1129 | 30.4 | 33.6 | 1376 |
| 4*1.5 | 11.4 | 13.1 | 199 | 12.4 | 14.1 | 225 |
| 5*1.5 | 12.4 | 14.1 | 243 | 13.4 | 15.2 | 273 |
| 7*1.5 | 13.7 | 15.4 | 302 | 15.0 | 16.9 | 363 |
| 10*1.5 | 17.6 | 19.8 | 460 | 19.2 | 21.4 | 519 |
| 12*1.5 | 18.4 | 20.7 | 517 | 20.0 | 22.3 | 603 |
| 14*1.5 | 19.4 | 21.6 | 581 | 21.1 | 23.4 | 677 |
| 16*1.5 | 20.4 | 22.7 | 669 | 22.2 | 24.5 | 766 |
| 19*1.5 | 21.7 | 24.1 | 763 | 23.6 | 26.1 | 873 |
| 24*1.5 | 25.5 | 28.2 | 974 | 28.2 | 31.1 | 1114 |
| 27*1.5 | 26.1 | 28.7 | 1083 | 28.8 | 31.8 | 1239 |
| 30*1.5 | 27.2 | 30.0 | 1180 | 30.1 | 33.2 | 1415 |
| 33*1.5 | 28.6 | 31.7 | 1280 | 31.2 | 34.3 | 1552 |
| 37*1.5 | 29.9 | 33.2 | 1452 | 32.6 | 35.9 | 1673 |
| 4*2.5 | 12.6 | 14.3 | 252 | 13.6 | 15.2 | 279 |
| 5*2.5 | 13.4 | 15.2 | 308 | 14.6 | 16.5 | 372 |
| 7*2.5 | 15.2 | 17.2 | 412 | 16.4 | 18.4 | 455 |
| 10*2.5 | 19.4 | 21.6 | 587 | 21.0 | 23.2 | 673 |
| 12*2.5 | 20.0 | 22.3 | 687 | 21.7 | 23.9 | 759 |
| 14*2.5 | 21.3 | 23.6 | 775 | 23.0 | 25.3 | 868 |
| 16*2.5 | 22.4 | 24.8 | 876 | 24.3 | 26.6 | 969 |
| 19*2.5 | 23.9 | 26.3 | 1005 | 25.8 | 28.3 | 1124 |
| 24*2.5 | 28.4 | 31.4 | 1280 | 30.7 | 33.8 | 1511 |
| 27*2.5 | 29.0 | 32.1 | 1426 | 31.4 | 34.5 | 1680 |
| 30*2.5 | 30.3 | 33.5 | 1622 | 32.8 | 35.9 | 1829 |
| 33*2.5 | 31.4 | 34.6 | 1772 | 34.0 | 37.2 | 1978 |
| 37*2.5 | 32.9 | 36.2 | 1928 | 35.6 | 38.9 | 2151 |
| 4*4 | 13.8 | 15.5 | 336 | 14.9 | 16.8 | 380 |
| 4*6 | 15.6 | 17.5 | 458 | 16.6 | 18.5 | 493 |
| 4*10 | 18.5 | 20.4 | 719 | 19.0 | 20.9 | 728 |
| 4*16 | 21.1 | 23.0 | 1021 | 21.6 | 23.5 | 1022 |
| 4*25 | 25.5 | 27.4 | 1555 | 25.9 | 27.9 | 1548 |
| 4*35 | 29.2 | 31.5 | 2093 | 30.4 | 32.7 | 2107 |
| 4*50 | 33.3 | 35.7 | 2791 | 34.5 | 36.9 | 2813 |
| 4*70 | 38.1 | 40.6 | 3738 | 39.3 | 41.8 | 3754 |
| 4*95 | 44.2 | 46.8 | 5057 | 45.4 | 48.0 | 5166 |
| 4*120 | 48.1 | 50.7 | 6168 | 49.3 | 51.9 | 6244 |
| 4*150 | 53.1 | 55.9 | 7667 | 54.3 | 57.1 | 7666 |
| 5*4 | 15.1 | 17.1 | 433 | 16.2 | 18.1 | 470 |
| 5*6 | 16.7 | 18.6 | 565 | 17.8 | 19.7 | 606 |
| 5*10 | 20.0 | 22.0 | 891 | 20.5 | 22.5 | 923 |
| 5*16 | 22.9 | 24.8 | 1311 | 23.4 | 25.4 | 1274 |
| 6*4 | 16.7 | 18.6 | 519 | 17.8 | 19.8 | 571 |
| 6*6 | 18.7 | 20.7 | 679 | 19.8 | 21.8 | 745 |
| 7*6 | 18.7 | 20.7 | 717 | 19.8 | 21.8 | 789 |
| 3*2.5+1*1.5 | 12.6 | 14.2 | 275 | 13.5 | 15.2 | 305 |
| 3*4+1*2.5 | 13.7 | 15.4 | 349 | 14.9 | 16.7 | 401 |
| 3*6+1*4 | 15.5 | 17.4 | 466 | 16.5 | 18.4 | 517 |
| 3*10+1*6 | 17.9 | 19.8 | 684 | 18.5 | 20.4 | 715 |
| 3*16+1*6 | 20.0 | 21.9 | 957 | 19.7 | 20.6 | 979 |
| 3*16+1*10 | 20.6 | 22.4 | 1020 | 21.0 | 22.9 | 1031 |
| 3*25+1*10 | 24.0 | 26.0 | 1383 | 24.5 | 26.5 | 1421 |
| 3*25+1*16 | 24.6 | 26.6 | 1481 | 25.0 | 27.0 | 1517 |
| 3*35+1*10 | 26.8 | 28.7 | 1729 | 27.8 | 29.8 | 1785 |
| 3*35+1*16 | 27.3 | 29.2 | 1842 | 28.3 | 30.3 | 1883 |
| 3*50+1*25 | 31.7 | 34.1 | 2564 | 32.7 | 35.1 | 2586 |
| 3*70+1*25 | 35.6 | 38.1 | 3306 | 36.7 | 39.1 | 3361 |
| 3*70+1*35 | 36.3 | 38.7 | 3439 | 37.5 | 39.9 | 3523 |
| 3*95+1*35 | 41.2 | 43.7 | 4448 | 42.4 | 44.9 | 4538 |
| 3*95+1*50 | 41.9 | 44.5 | 4618 | 43.1 | 45.7 | 4752 |
| 3*120+1*35 | 44.3 | 46.9 | 5253 | 45.5 | 48.1 | 5355 |
| 3*120+1*50 | 45.1 | 47.7 | 5449 | 46.3 | 48.9 | 5541 |
| 3*150+1*50 | 49.2 | 51.9 | 6561 | 50.4 | 53.1 | 6604 |
| 3*185+1*50 | 54.2 | 57.4 | 7943 | 55.4 | 58.6 | 7990 |
| Note: Data above only for reference.confirmation needed by our technical department. We reserve the right to alter all information without notice. | ||||||
