0.6/1kV XLPE Marine Electrical Wire CJPFR/SC CJPJR/SC Boat Electrical Cable

0.6/1kV XLPE Marine Electrical Wire CJPFR/SC CJPJR/SC Boat Electrical Cable

0.6/1kV XLPE Marine Electrical Wire CJPFR/SC CJPJR/SC Boat Electrical Cable

Brand Name: JIANGNAN CABLE
Model Number: CJPFR/SC CJPJR/SC
MOQ: 100 Meter
Price: US$1.00~US$20.00
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CCS BV
Product Name:
Marine Power Cable
Executive Standard:
IEC60092-353
Rated Voltage:
0.6/1kV
Fire Resistance Standard:
IEC60331-21
Minimum Bending Radius:
6 Times The Diameter Of The Cable
Oversheath Material:
Crosslinked Polyolefin
Packaging Details:
DRUM
Highlight:

0.6/1kV XLPE Marine Electrical Wire

,

Marine Electrical Wire CJPFR/SC

,

CJPJR/SC Boat Electrical Cable

Product Description

CJPFR/SC CJPJR/SC 0.6/1kV Rated Voltage XLPE Insulated Marine Power Cable with Competitive Price and High Performance

0.6/1kV Rated Voltage XLPE Insulated Marine Power Cable
Executive Standard
This product complies with IEC60092-353 standard.
Cable Categories and Types
  • CJV/DA/SA/NA: XLPE insulated polyvinyl chloride sheathed marine power cable DA SA NA type
  • CJV80/DA/SA/NA: XLPE insulated polyvinyl chloride inner sheathed copper wire braided armoring power cable for shipment type DA SA NA
  • CJV90/DA/SA/NA: XLPE insulated polyvinyl chloride inner sheathed steel wire braided armoring power cable for shipment type DA SA NA
  • CJV82/DA/SA/NA: XLPE insulated PVC inner sheathed copper wire braided armoring PVC outer sheathed marine power cable DA SA NA type
  • CJV92/DA/SA/NA: XLPE insulated PVC inner sheathed wire braided armoring PVC outer sheathed marine power cable DA SA NA type
  • CJPJ/SC/NC: XLPE insulated crosslinked polyolefin outer sheathed marine power cable SC NC type
  • CJPJ80/SC/NC: XLPE insulated XLPE inner sheathed copper wire braided armoring power cable for marine type SC NC
  • CJPJ90/SC/NC: XLPE insulated crosslinked polyolefin inner sheathed steel wire braided armoring power cable for marine type SC NC
  • CJPJ85/SC/NC: XLPE insulated crosslinked polyolefin copper wire braided armoring power cable for marine type SC NC
  • CJPJ95/SC/NC: XLPE insulated crosslinked polyolefin inner sheathed wire braided armoring crosslinked polyolefin outer sheathed marine power cable SC NC type
  • CJPF/SC/NC: XLPE insulated polyolefin sheathed marine power cable SC NC type
  • CJPF80/SC/NC: XLPE insulated polyolefin inner sheathed copper wire braided armoring power cable for marine type SC NC
  • CJPF90/SC/NC: XLPE insulated polyolefin inner sheathed steel wire braided armoring marine power cable SC NC type
  • CJPF86/SC/NC: XLPE insulated polyolefin inner sheathed copper wire braided armored polyolefin outer sheathed marine power cable SC NC type
  • CJPF96/SC/NC: XLPE insulated polyolefin inner sheathed wire braided armored polyolefin outer sheathed marine power cable SC NC type
  • CJPJR/SC: XLPE insulated crosslinked polyolefin sheathed marine power flexible cable type SC
  • CJPFR/SC: XLPE insulated polyolefin sheathed marine power flexible cable type SC
  • CJ82/DA/SA/NA: XLPE insulated copper wire braided armoring PVC sheathed marine power cable SC NC type
  • CJ92/DA/SA/NA: XLPE insulated wire braided armoring polyvinyl chloride sheathed marine power cable SC NC type
  • CJ85/SC/NC: XLPE insulated copper wire braided armoring crosslinked polyolefin outer sheathed marine power cable SC NC type
  • CJ95/SC/NC: XLPE insulated wire braided armoring crosslinked polyolefin outer sheathed marine power cable SC NC type
  • CJ86/SC/NC: XLPE insulated copper wire braided armoring polyolefin outer sheathed marine power cable SC NC type
  • CJ96/SC/NC: XLPE insulated wire braided armoring polyolefin outer sheathed marine power cable SC NC type
Product Application
This product is suitable for electric power and lighting equipment in water structures such as cabins and offshore oil platforms.
Cable Parameters
Rated voltage of 0.6/1kV
No.of cores
×sectional area		 CJPFR/SC CJPJR/SC
Over diam.mm Approx. weight
Nom. Max
1*1 4.7  6.3  43
1*1.5 4.9  6.5  48
1*2.5 5.4  7.0  61
1*4 5.9  7.5  77
1*6 6.5  8.1  99
1*10 7.6  9.2  149
1*16 8.6  10.2  211
1*25 10.5  12.1  312
1*35 12.1  13.7  413
1*50 13.7  15.3  567
1*70 15.8  17.4  767
1*95 17.6  19.2  996
1*120 19.4  21.0  1245
1*150 21.5  23.1  1546
1*185 23.7  25.3  1881
1*240 26.8  28.4  2459
1*300 29.6  31.2  3020
2*1 8.0  9.8  84
2*1.5 8.4  10.2  102
2*2.5 9.6  11.4  131
2*4 10.6  12.4  170
2*6 11.8  13.6  227
2*10 14.2  16.0  352
2*16 16.4  18.2  493
2*25 20.0  21.8  733
2*35 23.4  25.2  980
2*50 26.4  28.2  1331
2*70 30.4  32.2  1830
2*95 34.4  36.2  2361
2*120 37.8  39.6  2931
3*1 8.4  10.2  104
3*1.5 8.8  10.7  121
3*2.5 10.1  12.0  159
3*4 11.2  13.0  217
3*6 12.7  14.5  285
3*10 15.1  16.9  451
3*16 17.4  19.2  642
3*25 21.3  23.1  960
3*35 24.9  26.8  1309
3*50 28.3  30.2  1794
3*70 32.6  34.5  2455
3*95 36.7  38.5  3204
3*120 40.6  42.4  3994
3*150 44.8  46.7  4978
3*185 50.0  51.8  6130
4*1 9.1  11.0  123
5*1 10.1  12.0  144
7*1 10.9  12.9  172
10*1 13.8  16.0  255
12*1 14.2  16.4  284
14*1 14.9  17.2  317
16*1 15.9  18.2  353
19*1 16.7  19.1  406
24*1 19.6  22.2  512
27*1 20.0  22.6  568
30*1 20.7  23.4  628
33*1 21.7  24.4  658
37*1 22.5  25.3  721
4*1.5 9.8  11.7  144
5*1.5 10.6  12.6  170
7*1.5 11.5  13.5  214
10*1.5 14.6  16.8  305
12*1.5 15.2  17.5  343
14*1.5 16.0  18.3  385
16*1.5 16.8  19.2  440
19*1.5 17.9  20.3  496
24*1.5 21.0  23.6  626
27*1.5 21.4  24.1  709
30*1.5 22.2  24.9  770
33*1.5 23.2  26.0  825
37*1.5 24.1  26.9  892
4*2.5 11.0  12.9  200
5*2.5 12.0  13.9  237
7*2.5 13.2  15.2  292
10*2.5 16.8  19.0  428
12*2.5 17.3  19.6  485
14*2.5 18.4  20.7  547
16*2.5 19.4  21.7  625
19*2.5 20.4  22.8  709
24*2.5 24.2  26.8  895
27*2.5 24.7  27.4  1011
30*2.5 25.6  28.3  1118
33*2.5 26.8  29.5  1187
37*2.5 27.8  30.6  1304
Note:  Data above only for reference.confirmation needed by our technical department. We reserve the right to alter all information without notice.

Technical Characteristics
  • The rated voltage of the cable is 0.6/1(1.2)kV
  • The allowable long-term operating temperature of the cable conductor is 90℃
  • The flame retardant performance conforms to IEC60332-1-2 or IEC60332-3-22 standards
  • The fire resistance conforms to IEC60331-21 standard
  • The minimum bending radius of a single-core cable is 6 times the diameter of the cable
Identification
  • Insulated core: white insulated with black numbering
  • Sheath printed with factory name, type, voltage, specification, length mark, etc.
Structure Diagram
0.6/1kV XLPE Marine Electrical Wire CJPFR/SC CJPJR/SC Boat Electrical Cable 0 0.6/1kV XLPE Marine Electrical Wire CJPFR/SC CJPJR/SC Boat Electrical Cable 1
