0.6/1kV Marine Power Wire Ethylene Propylene Insulated Shore Power Cables

0.6/1kV Marine Power Wire Ethylene Propylene Insulated Shore Power Cables

0.6/1kV Marine Power Wire Ethylene Propylene Insulated Shore Power Cables

Brand Name: JIANGNAN CABLE
Model Number: CEF80/DA/SA CEF90/DA/SA CEH80/DA/SA CEH90/DA/SA CEV80/DA/SA CEV90/DA/SA CEPJ80/SC CEPJ90/SC CEPF80/SC CEPF90/SC CEF80/NA CEF90/NA CEH80/NA CEH90/NA CEV80/NA CEV90/NA CEPJ80/NC CEPJ90/NC CEPF80/NC CEPF90/NC
MOQ: 100 Meter
Price: US$1.00~US$20.00
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CCS BV
Item Name:
Marine And Ocean Project Cable
Usage:
Power, Lighting, Communication And Control Systems For Various Marine Ships
Certificates:
Certificate Of CCS And BV
PVC/XLPE:
Nice Electrical Insulation Properties
Fireproof:
Excellent Fire Resistance Performance
Characteristics:
Very High Resistance To Pressure, Abrasion, Corrosion Etc.
Packaging Details:
DRUM
Highlight:

0.6/1kV Marine Power Wire

,

Ethylene Propylene Shore Power Cables

,

0.6/1kV Shore Power Cables

Product Description

0.6/1kV Rated Voltage Ethylene-propylene Insulated Marine Power Cable with 90°C Operating Temperature and Flame Retardant CEF80/DA/SA

0.6/1kV Rated Voltage Ethylene-propylene Insulated Marine Power Cable
Executive Standard
This product complies with IEC60092-353 standard.
Cable Categories and Types

  • CEFR/DA/SA: Ethylene propylene insulated neoprene sheathed marine power flexible cable

    CEFRP/DA/SA: Ethylene propylene insulated copper wire shielded neoprene outer sheathed marine power flexible cable type

    CEF/DA/SA/NA: Ethylene propylene insulated neoprene sheathed marine power cable DA SA NA type

    CEF80/DA/SA/NA: Ethylene propylene insulated neoprene inner sheathed copper wire braided armoring power cable for marine type

    CEF90/DA/SA/NA:Ethylene propylene insulated neoprene inner sheathed steel wire braided armoring power cable for marine

    CEF82/DA/SA/NA: Ethylene propylene insulated neoprene inner sheathed copper braided armouring polyvinyl chloride outer sheathed marine power cable

    CEF92/DA/SA/NA: Ethylene propylene chloroprene inner sheathed wire braided armored PVC outer sheathed marine power cable

    CEH/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene outer sheathed marine power cable DA SA NA type

    CEH80/DA/SA/NA:

    Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed copper wire braided armoring power cable for marine

    CEH90/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed steel wire braided armoring power cable for marine

    CEH82/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed copper wire braided armored polyvinyl chloride outer sheathed marine power cable

    CEH92/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed wire braided armored polyvinyl chloride outer sheathed marine power cable

    CEV/DA/SA/NA: Ethylene propylene insulated polyvinyl chloride sheathed marine power cable

    CEV80/DA/SA/NA: Ethylene propylene inulatedpolnhlridennesheathedcoewirebraidedarmorsormarnepowecabldstype

    CEV90/DA/SA/NA: Ethylene propylene insulated polyvinyl chloride inner sheathed steel wire braided armors for marine power cable

    CEV82/DA/SA/NA: Ethylene propylene insulated PVC inner sheathed copper wire braided armored PVC outer sheathed marine power cable DA SA NA type

    CEV92/DA/SA/NA: Ethylene propylene insulated PVC inner sheathed wire braided armored PVC outer sheathed marine power cable

    CEPJ/SC/NC: Ethylene-propylene insulated cross-linked polyolefin outer sheathed marine power cable SC NC type

    CEPJ8O/SC/NC: Ethylene propylene insulated cross-linked polyolefin inner sheathed copper wire braided armoring power cable for marine

    CEPJ90/SC/NC: Ethylene-propylene insulated cross-linked polyolefin inner sheathed steel wire braided armors for marine power cable SC NC type

    CEPJ85/SC/NC: Ethylene propylene insulated cross-linked polyolefin inner sheathed copper wire braided armoring cross-linked Polyolefin outer sheathed marine power cable

    CEPJ95/SC/NC: Ethylene-propylene insulated cross-linked polyolefin inner sheathed wire braided armoring cross-linked polyolefin outer sheathed marine power cable

    CEPF/SC/NC: Ethylene propylene insulated polyolefin outer sheathed marine power cable SC NC type

    CEPF80/SC/NC: Ethylene propylene insulated polyolefin inner sheathed copper wire braided armoring for marine power cable SC NC type

Product Application
This product is suitable for electric power and lighting equipment in water structures such as cabins and offshore oil platforms.
Cable Parameters
Ethylene-propylene Insulated Marine Power Cable at Rated Voltage of 0.6/1kV
No.of cores
×sectional

area		 CEF80/DASA CEF90/DASA CEH80/DASA CEH90/DASA CEV80/DASA CEV90/DASA CEPJ80/SC CEPJ90/SC CEPF80/SC CEPF90/SC CEF80/NA CEF90/NA CEH80/NA CEH90/NA CEV80/NA CEV90/NA CEPJ80/NC CEPJ90/NC CEPF80/NC CEPF90/NC
Over diam.mm Approx.weight Over diam.mm Approx.weight
Nom. Max TYPE 80 TYPE 90 Nom. Max TYPE 80 TYPE 90
1*1 6.9  8.3  80    7.3  8.7  88
1*1.5 7.2  8.6  89  / 7.6  9.0  98  /
1*2.5 7.6  9.0  110  8.0  9.4  113
1*4 8.1  9.5  132  8.5  9.9  135
1*6 8.7  10.1  159  9.1  10.5  162
1*10 9.8  11.2  221  10.0  11.4  215
1*16 10.8  12.2  291  11.0  12.4  286
1*25 12.4  13.8  409  12.6  14.0  401
1*35 13.8  15.2  512  14.3  15.7  520
1*50 15.4  16.8  718  16.3  17.9  726
1*70 17.6  19.2  938  18.1  19.7  948
1*95 19.9  21.5  1233  20.4  22.0  1285
1*120 21.4  23.0  1499  21.9  23.5  1530
1*150 23.6  25.2  1823  24.1  25.7  1838
1*185 26.3  28.2  2274  26.8  28.7  2291
1*240 29.4  31.3  2878  29.9  31.8  2895
1*300 32.8  35.1  3623  33.3  35.6  3642
2*1 10.7  12.3  166  200  11.5  13.1  179  175
2*1.5 11.3  12.9  188  175  12.1  13.7  201  196
2*2.5 12.1  13.7  223  209  12.9  14.5  236  231
2*4 13.1  14.7  272  313  13.9  15.5  298  291
2*6 14.3  15.9  335  380  15.1  16.7  386  378
2*10 16.9  18.7  558  589  17.3  19.1  564  552
2*16 18.9  20.7  748  783  19.3  21.1  756  743
2*25 22.1  23.9  1052  1093  22.5  24.3  1055  1040
2*35 25.4  27.2  1331  1377  26.4  28.2  1385  1363
2*50 29.0  30.9  1777  1789  30.4  32.6  1859  1834
2*70 33.2  35.5  2474  2571  34.2  36.5  2491  2461
2*95 38.1  40.4  3289  3345  39.1  41.4  3291  3257
2*120 41.3  43.7  3892  3953  42.3  44.7  3952  3908
3*1 11.2  12.9  189  224  12.1  13.7  204  200
3*1.5 11.9  13.5  209  254  12.7  14.4  233  228
3*2.5 12.7  14.4  262  301  13.6  15.2  278  273
3*4 13.8  15.4  327  369  14.7  16.3  356  349
3*6 15.1  16.7  409  456  16.2  18.0  489  478
3*10 17.9  19.7  671  703  18.3  20.2  673  660
3*16 20.0  21.9  919  955  20.5  22.3  951  937
3*25 23.7  25.6  1371  1414  24.6  26.4  1412  1391
3*35 27.2  29.1  1747  1757  28.2  30.1  1772  1749
3*50 31.2  33.4  2353  2365  32.2  34.5  2408  2381
3*70 35.5  37.9  3149  3250  36.6  39.0  3176  3145
3*95 40.7  43.2  4225  4284  41.8  44.3  4323  4280
3*120 44.2  46.7  5163  5227  45.3  47.8  5254  5208
3*150 48.8  51.4  6281  6351  49.9  52.5  6337  6287
3*185 54.7  57.8  7849  7775  55.8  58.9  7898  7823
4*1 12.1  13.8  221  259  13.1  14.8  240  235
5*1 12.8  14.5  263  303  13.9  15.6  297  290
7*1 14.0  15.8  315  360  15.2  16.9  358  350
10*1 17.5  19.7  495  515  19.1  21.3  550  537
12*1 18.0  20.2  531  564  19.6  21.9  605  591
14*1 18.9  21.2  588  623  20.6  22.9  693  678
16*1 19.8  22.2  646  682  21.6  24.0  770  754
19*1 20.8  23.2  749  788  22.8  25.1  855  839
24*1 24.7  27.4  932  977  27.1  29.7  1119  1095
27*1 25.5  28.1  1031  1079  27.9  30.5  1238  1212
30*1 26.3  29.1  1129  1179  29.1  32.2  1352  1325
33*1 27.3  30.1  1231  1242  30.2  33.3  1434  1407
37*1 28.5  31.4  1325  1336  31.6  34.8  1603  1575
4*1.5 12.8  14.5  255  295  13.8  15.5  287  280
5*1.5 13.6  15.3  303  346  14.6  16.4  339  332
7*1.5 14.9  16.6  369  417  16.3  18.3  463  452
10*1.5 18.7  20.9  576  612  20.2  22.4  634  619
12*1.5 19.2  21.5  624  659  20.8  23.1  724  709
14*1.5 20.2  22.4  693  730  21.9  24.2  803  788
16*1.5 21.2  23.5  789  828  23.0  25.3  899  883
19*1.5 22.5  24.9  888  929  24.8  27.3  1049  1028
24*1.5 26.7  29.4  1159  1170  29.4  32.3  1321  1295
27*1.5 27.3  29.9  1283  1294  30.0  33.0  1463  1435
30*1.5 28.4  31.2  1388  1400  31.3  34.4  1653  1624
33*1.5 29.8  32.9  1484  1496  32.4  35.5  1787  1758
37*1.5 31.1  34.4  1669  1681  33.8  37.1  1917  1886
4*2.5 13.8  15.5  312  355  14.8  16.4  345  337
5*2.5 14.6  16.4  373  419  15.9  17.8  469  458
7*2.5 16.3  18.3  510  540  17.4  19.4  562  550
10*2.5 20.2  22.4  713  751  21.8  24.0  798  783
12*2.5 20.8  23.1  805  843  22.5  24.7  888  873
14*2.5 22.1  24.4  898  938  24.2  26.5  1040  1018
16*2.5 23.2  25.6  1007  1049  25.5  27.8  1149  1127
19*2.5 25.1  27.5  1142  1186  27.0  29.5  1315  1292
24*2.5 29.6  32.6  1482  1493  31.9  35.0  1743  1714
27*2.5 30.2  33.3  1645  1657  32.6  35.7  1930  1899
30*2.5 31.5  34.7  1854  1867  34.0  37.1  2088  2056
33*2.5 32.6  35.8  2002  2098  35.2  38.4  2233  2201
37*2.5 34.1  37.4  2166  2264  36.8  40.1  2415  2382
4*4 15.0  16.7  394  440  16.2  18.1  477  466
4*6 16.7  18.6  555  585  17.6  19.5  590  578
4*10 19.5  21.4  827  863  20.0  21.9  838  825
4*16 21.9  23.8  1146  1183  22.4  24.3  1147  1132
4*25 26.7  28.6  1738  1748  27.1  29.1  1733  1710
4*35 30.4  32.7  2302  2314  31.6  33.9  2320  2294
4*50 34.5  36.9  3031  3130  35.7  38.1  3057  3026
4*70 39.3  41.8  4065  4121  40.5  43.0  4029  3995
4*95 45.4  48.0  5431  5496  46.6  49.2  5546  5499
4*120 49.3  51.9  6576  6647  50.5  53.1  6657  6606
4*150 54.7  57.5  8268  8193  55.9  58.7  8275  8200
5*4 16.2 18.1 529 559 17.2 19.2 575  563
5*6 17.7  19.7  663  695  18.8  20.7  711  698
5*10 20.8  22.8  1008  1047  21.3  23.3  1045  1030
5*16 23.7  25.6  1446  1489  24.6  26.6  1446  1425
6*4 17.7  19.7  626  658  18.9  20.9  677  664
6*6 19.5  21.5  786  821  20.6  22.6  863  849
7*6 19.5  21.5  825  860  20.6  22.6  907  893
3*2.5+1*1.5 13.8  15.4  335  377  14.7  16.4  370  363
3*4+1*2.5 14.9  16.6  413  458  16.1  18.0  473  465
3*6+1*4 16.5  18.4  561  590  17.5  19.4  620  609
3*10+1*6 18.9  20.8  789  823  19.5  21.4  822  808
3*16+1*6 20.8  22.7  1073  1111  20.5  21.4  1098  1083
3*16+1*10 21.4  23.2  1140  1179  21.8  23.7  1153  1137
3*25+1*10 25.2  27.2  1520  1564  25.7  27.7  1594  1573
3*25+1*16 25.8  27.8  1621  1667  26.2  28.2  1696  1674
3*35+1*10 28.0  29.9  1916  1926  29.0  31.0  1975  1952
3*35+1*16 28.5  30.4  2033  2043  29.5  31.5  2078  2054
3*50+1*25 32.9  35.3  2791  2885  33.9  36.3  2816  2788
3*70+1*25 36.8  39.3  3606  3659  37.9  40.3  3614  3583
3*70+1*35 37.5  39.9  3745  3798  38.7  41.1  3784  3752
3*95+1*35 42.4  44.9  4791  4851  43.6  46.1  4887  4844
3*95+1*50 43.1  45.7  4970  5031  44.3  46.9  5112  5068
3*120+1*35 45.5  48.1  5620  5684  46.7  49.3  5729  5683
3*120+1*50 46.3  48.9  5827  5893  47.5  50.1  5924  5876
3*150+1*50 50.4  53.1  6969  7040  51.6  54.3  7018  6967
3*185+1*50 55.8  59.0  8540  8466  57.0  60.2  8596  8522
Note:  Data above only for reference.confirmation needed by our technical department. We reserve the right to alter all information without notice.

Technical Characteristics
  • The rated voltage of the cable is 0.6/1(1.2)kV
  • The allowable long-term operating temperature of the cable conductor is 90℃
  • The flame retardant performance conforms to IEC60332-1-2 or IEC60332-3-22 standards
  • The fire resistance conforms to IEC60331-21 standard
  • The minimum bending radius of a single-core cable is 6 times the diameter of the cable
Identification
  • Insulated core: white insulated with black numbering
  • Sheath printed with factory name, type, voltage, specification, length mark, etc.
Structure Diagram
0.6/1kV Marine Power Wire Ethylene Propylene Insulated Shore Power Cables 0   0.6/1kV Marine Power Wire Ethylene Propylene Insulated Shore Power Cables 1

Tags:

shipboard power cable

boat power cables

marine power wire

RELATED PRODUCTS
Flameproof Marine Control Cable CKEF82 DA SA Boat Motor Control Cables

Flameproof Marine Control Cable CKEF82 DA SA Boat Motor Control Cables

Chat Now
Crosslinked Polyethylene Insulated Marine Power Cable 8.7/15kV Electrical Wire For Boats

Crosslinked Polyethylene Insulated Marine Power Cable 8.7/15kV Electrical Wire For Boats

Chat Now
CJ92 CJ95 CJ96 Series Marine Power Cable Fireproof Boat Power Cable

CJ92 CJ95 CJ96 Series Marine Power Cable Fireproof Boat Power Cable

Chat Now
Fire Resistant Boat Cable Wire Tinned Copper Conductor Marine Cables

Fire Resistant Boat Cable Wire Tinned Copper Conductor Marine Cables

Chat Now
XLPE Insulated Marine Communication Cable Wire For Boat Electronics

XLPE Insulated Marine Communication Cable Wire For Boat Electronics

Chat Now
+86 15258895859
Quick link
Home About Us Products Cases News download video CONTACT US
Quick Contact

Address

No.196 Of LongPu Road,Fuyang district, Hangzhou City, ZheJiang Province 311400,China

Tel

86-15258895859

+86 15258895859
Our Newsletter
Subscribe to our newsletter for discounts and more.
Privacy Policy |  Sitemap  | China Good Quality Marine Ventilator Supplier. Copyright © 2009-2026 Hangzhou Fuyang Mykey Imp & Exp Co., Ltd. . All Rights Reserved.
