| Brand Name: | JIANGNAN CABLE |
| Model Number: | CE82/DA/SA CE85/SC CE86/SC CE82/NA CE85/NC CE86/NC |
| MOQ: | 100 Meter |
| Price: | US$1.00~US$20.00 |
| Payment Terms: | T/T |
0.6/1kV Rated Voltage Marine Power Cable with Ethylene-propylene Insulation for 90°C Operating Temperature and Flame Retardant Performance CE82/DA/SA
CEFR/DA/SA: Ethylene propylene insulated neoprene sheathed marine power flexible cable
CEFRP/DA/SA: Ethylene propylene insulated copper wire shielded neoprene outer sheathed marine power flexible cable type
CEF/DA/SA/NA: Ethylene propylene insulated neoprene sheathed marine power cable DA SA NA type
CEF80/DA/SA/NA: Ethylene propylene insulated neoprene inner sheathed copper wire braided armoring power cable for marine type
CEF90/DA/SA/NA:Ethylene propylene insulated neoprene inner sheathed steel wire braided armoring power cable for marine
CEF82/DA/SA/NA: Ethylene propylene insulated neoprene inner sheathed copper braided armouring polyvinyl chloride outer sheathed marine power cable
CEF92/DA/SA/NA: Ethylene propylene chloroprene inner sheathed wire braided armored PVC outer sheathed marine power cable
CEH/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene outer sheathed marine power cable DA SA NA type
CEH80/DA/SA/NA:
Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed copper wire braided armoring power cable for marine
CEH90/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed steel wire braided armoring power cable for marine
CEH82/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed copper wire braided armored polyvinyl chloride outer sheathed marine power cable
CEH92/DA/SA/NA: Ethylene-propylene insulated chlorosulfonated polyethylene inner sheathed wire braided armored polyvinyl chloride outer sheathed marine power cable
CEV/DA/SA/NA: Ethylene propylene insulated polyvinyl chloride sheathed marine power cable
CEV80/DA/SA/NA: Ethylene propylene inulatedpolnhlridennesheathedcoewirebraidedarmorsormarnepowecabldstype
CEV90/DA/SA/NA: Ethylene propylene insulated polyvinyl chloride inner sheathed steel wire braided armors for marine power cable
CEV82/DA/SA/NA: Ethylene propylene insulated PVC inner sheathed copper wire braided armored PVC outer sheathed marine power cable DA SA NA type
CEV92/DA/SA/NA: Ethylene propylene insulated PVC inner sheathed wire braided armored PVC outer sheathed marine power cable
CEPJ/SC/NC: Ethylene-propylene insulated cross-linked polyolefin outer sheathed marine power cable SC NC type
CEPJ8O/SC/NC: Ethylene propylene insulated cross-linked polyolefin inner sheathed copper wire braided armoring power cable for marine
CEPJ90/SC/NC: Ethylene-propylene insulated cross-linked polyolefin inner sheathed steel wire braided armors for marine power cable SC NC type
CEPJ85/SC/NC: Ethylene propylene insulated cross-linked polyolefin inner sheathed copper wire braided armoring cross-linked Polyolefin outer sheathed marine power cable
CEPJ95/SC/NC: Ethylene-propylene insulated cross-linked polyolefin inner sheathed wire braided armoring cross-linked polyolefin outer sheathed marine power cable
CEPF/SC/NC: Ethylene propylene insulated polyolefin outer sheathed marine power cable SC NC type
CEPF80/SC/NC: Ethylene propylene insulated polyolefin inner sheathed copper wire braided armoring for marine power cable SC NC type
| Ethylene-propylene Insulated Marine Power Cable at Rated Voltage of 0.6/1kV | ||||||
| No.of cores ×sectional area |
CE82/DA/SA CE85/SC CE86/SC | CE82/NA CE85/NC CE86/NC | ||||
| Over diam.mm | Approx.weight | Over diam.mm | Approx.weight | |||
| Nom. | Max | TYPE 82/85/86 | Nom. | Max | TYPE 82/85/86 | |
| 1*1 | 5.9 | 7.5 | 60 | 6.3 | 7.9 | 67 |
| 1*1.5 | 6.2 | 7.8 | 68 | 6.6 | 8.2 | 76 |
| 1*2.5 | 6.6 | 8.2 | 83 | 7.0 | 8.6 | 91 |
| 1*4 | 7.1 | 8.7 | 103 | 7.5 | 9.1 | 111 |
| 1*6 | 7.7 | 9.3 | 128 | 8.1 | 9.7 | 141 |
| 1*10 | 9.0 | 10.6 | 190 | 9.2 | 10.8 | 193 |
| 1*16 | 10.0 | 11.6 | 266 | 10.2 | 11.8 | 262 |
| 1*25 | 11.8 | 13.4 | 387 | 12.0 | 13.6 | 381 |
| 1*35 | 13.1 | 14.7 | 488 | 13.6 | 15.2 | 492 |
| 1*50 | 14.9 | 16.5 | 652 | 15.4 | 17.0 | 649 |
| 1*70 | 16.8 | 18.4 | 874 | 17.3 | 18.9 | 883 |
| 1*95 | 19.5 | 21.1 | 1196 | 20.0 | 21.6 | 1226 |
| 1*120 | 21.2 | 22.8 | 1437 | 21.7 | 23.3 | 1468 |
| 1*150 | 23.9 | 25.5 | 1755 | 24.4 | 26.0 | 1770 |
| 1*185 | 26.2 | 28.0 | 2163 | 26.7 | 28.5 | 2179 |
| 1*240 | 29.5 | 31.3 | 2755 | 30.0 | 31.8 | 2808 |
| 1*300 | 32.5 | 34.3 | 3441 | 33.0 | 34.8 | 3460 |
| 2*1 | 9.8 | 11.6 | 145 | 10.6 | 12.4 | 157 |
| 2*1.5 | 10.4 | 12.2 | 166 | 11.2 | 13.0 | 184 |
| 2*2.5 | 11.2 | 13.0 | 205 | 12.0 | 13.8 | 219 |
| 2*4 | 12.4 | 14.2 | 254 | 13.2 | 15.0 | 268 |
| 2*6 | 13.6 | 15.4 | 324 | 14.4 | 16.2 | 339 |
| 2*10 | 16.1 | 17.9 | 461 | 16.5 | 18.3 | 481 |
| 2*16 | 18.3 | 20.1 | 633 | 18.9 | 20.7 | 646 |
| 2*25 | 21.9 | 23.7 | 990 | 22.3 | 24.1 | 972 |
| 2*35 | 25.3 | 27.1 | 1254 | 26.3 | 28.1 | 1274 |
| 2*50 | 28.9 | 30.7 | 1657 | 29.9 | 31.7 | 1712 |
| 2*70 | 32.7 | 34.5 | 2227 | 33.7 | 35.5 | 2266 |
| 2*95 | 37.7 | 39.5 | 2964 | 38.7 | 40.5 | 3028 |
| 2*120 | 40.9 | 42.7 | 3558 | 41.9 | 43.7 | 3643 |
| 3*1 | 10.3 | 12.1 | 167 | 11.2 | 13.0 | 187 |
| 3*1.5 | 10.9 | 12.8 | 184 | 11.8 | 13.6 | 215 |
| 3*2.5 | 12.0 | 13.8 | 227 | 12.9 | 14.7 | 259 |
| 3*4 | 13.1 | 14.9 | 308 | 14.0 | 15.8 | 332 |
| 3*6 | 14.4 | 16.2 | 398 | 15.2 | 17.1 | 416 |
| 3*10 | 17.1 | 18.9 | 588 | 17.5 | 19.3 | 601 |
| 3*16 | 19.6 | 21.5 | 843 | 20.1 | 21.9 | 858 |
| 3*25 | 24.1 | 25.9 | 1264 | 24.5 | 26.3 | 1275 |
| 3*35 | 26.9 | 28.7 | 1614 | 27.9 | 29.8 | 1639 |
| 3*50 | 30.9 | 32.7 | 2203 | 32.0 | 33.8 | 2228 |
| 3*70 | 35.0 | 36.8 | 2927 | 36.1 | 37.9 | 2957 |
| 3*95 | 40.3 | 42.2 | 3921 | 41.4 | 43.3 | 4012 |
| 3*120 | 43.8 | 45.6 | 4785 | 44.9 | 46.7 | 4846 |
| 3*150 | 48.5 | 50.3 | 5870 | 49.5 | 51.4 | 5916 |
| 3*185 | 53.6 | 55.9 | 7231 | 54.7 | 57.0 | 7283 |
| 4*1 | 11.2 | 13.1 | 205 | 12.2 | 14.0 | 223 |
| 5*1 | 12.1 | 14.0 | 238 | 13.1 | 15.1 | 259 |
| 7*1 | 13.1 | 15.1 | 275 | 14.2 | 16.2 | 308 |
| 10*1 | 16.9 | 19.1 | 403 | 18.6 | 20.8 | 447 |
| 12*1 | 17.4 | 19.6 | 441 | 19.2 | 21.4 | 538 |
| 14*1 | 18.5 | 20.7 | 496 | 20.2 | 22.4 | 602 |
| 16*1 | 19.4 | 21.7 | 583 | 21.2 | 23.5 | 667 |
| 19*1 | 20.6 | 23.0 | 662 | 23.1 | 25.5 | 798 |
| 24*1 | 24.7 | 27.3 | 859 | 27.0 | 29.6 | 995 |
| 27*1 | 25.2 | 27.8 | 968 | 27.8 | 30.4 | 1159 |
| 30*1 | 26.3 | 28.9 | 1050 | 28.9 | 31.6 | 1256 |
| 33*1 | 27.2 | 29.9 | 1105 | 30.0 | 32.7 | 1318 |
| 37*1 | 28.4 | 31.1 | 1221 | 31.1 | 33.9 | 1455 |
| 4*1.5 | 12.1 | 14.0 | 238 | 13.1 | 15.0 | 259 |
| 5*1.5 | 12.9 | 14.8 | 276 | 13.9 | 15.8 | 308 |
| 7*1.5 | 14.1 | 16.1 | 332 | 15.3 | 17.3 | 361 |
| 10*1.5 | 18.1 | 20.2 | 477 | 19.8 | 22.0 | 557 |
| 12*1.5 | 18.8 | 21.0 | 550 | 20.4 | 22.6 | 628 |
| 14*1.5 | 19.9 | 22.2 | 627 | 21.7 | 23.9 | 705 |
| 16*1.5 | 21.0 | 23.3 | 697 | 23.4 | 25.7 | 825 |
| 19*1.5 | 22.0 | 24.4 | 805 | 24.6 | 27.0 | 938 |
| 24*1.5 | 26.6 | 29.2 | 1040 | 29.2 | 31.7 | 1222 |
| 27*1.5 | 27.2 | 29.8 | 1158 | 29.8 | 32.4 | 1361 |
| 30*1.5 | 28.3 | 31.0 | 1274 | 30.8 | 33.5 | 1493 |
| 33*1.5 | 29.5 | 32.2 | 1345 | 32.1 | 34.8 | 1572 |
| 37*1.5 | 30.6 | 33.4 | 1526 | 33.3 | 36.1 | 1737 |
| 4*2.5 | 13.1 | 15.0 | 296 | 14.0 | 15.9 | 323 |
| 5*2.5 | 14.1 | 16.0 | 352 | 15.2 | 17.1 | 379 |
| 7*2.5 | 15.3 | 17.3 | 420 | 16.6 | 18.6 | 471 |
| 10*2.5 | 20.0 | 22.2 | 639 | 21.6 | 23.7 | 689 |
| 12*2.5 | 20.6 | 22.8 | 710 | 22.2 | 24.4 | 794 |
| 14*2.5 | 21.7 | 23.9 | 801 | 24.0 | 26.2 | 926 |
| 16*2.5 | 23.6 | 25.9 | 933 | 25.4 | 27.7 | 1043 |
| 19*2.5 | 24.8 | 27.2 | 1067 | 26.7 | 29.1 | 1192 |
| 24*2.5 | 29.4 | 31.9 | 1348 | 31.7 | 34.3 | 1545 |
| 27*2.5 | 30.0 | 32.6 | 1504 | 32.4 | 35.0 | 1721 |
| 30*2.5 | 31.0 | 33.7 | 1696 | 33.5 | 36.1 | 1891 |
| 33*2.5 | 32.3 | 35.0 | 1797 | 34.9 | 37.6 | 2003 |
| 37*2.5 | 33.5 | 36.3 | 1989 | 36.3 | 39.0 | 2217 |
| 4*4 | 14.5 | 16.4 | 383 | 15.5 | 17.3 | 407 |
| 4*6 | 16.1 | 17.9 | 483 | 17.0 | 18.9 | 536 |
| 4*10 | 19.1 | 21.0 | 723 | 19.6 | 21.5 | 785 |
| 4*16 | 21.7 | 23.6 | 1043 | 22.2 | 24.1 | 1087 |
| 4*25 | 26.4 | 28.3 | 1603 | 26.9 | 28.8 | 1619 |
| 4*35 | 29.9 | 31.8 | 2089 | 31.1 | 33.0 | 2139 |
| 4*50 | 34.2 | 36.1 | 2805 | 35.4 | 37.3 | 2840 |
| 4*70 | 38.7 | 40.6 | 3761 | 39.9 | 41.8 | 3801 |
| 4*95 | 44.9 | 46.8 | 5102 | 46.3 | 48.2 | 5171 |
| 4*120 | 48.9 | 50.8 | 6162 | 50.1 | 52.0 | 6290 |
| 4*150 | 53.9 | 55.8 | 7563 | 55.1 | 57.0 | 7625 |
| 5*4 | 15.4 | 17.4 | 452 | 16.6 | 18.5 | 502 |
| 5*6 | 17.1 | 19.0 | 590 | 18.2 | 20.1 | 635 |
| 5*10 | 20.4 | 22.3 | 912 | 20.9 | 22.8 | 933 |
| 5*16 | 23.8 | 25.7 | 1308 | 24.3 | 26.3 | 1331 |
| 6*4 | 16.9 | 18.9 | 540 | 18.1 | 20.0 | 589 |
| 6*6 | 19.0 | 21.0 | 719 | 20.2 | 22.2 | 784 |
| 7*6 | 19.0 | 21.0 | 780 | 20.2 | 22.2 | 848 |
| 3*2.5+1*1.5 | 12.8 | 14.7 | 280 | 13.8 | 15.7 | 307 |
| 3*4+1*2.5 | 14.2 | 16.1 | 361 | 15.2 | 17.1 | 385 |
| 3*6+1*4 | 15.6 | 17.5 | 461 | 16.7 | 18.6 | 507 |
| 3*10+1*6 | 18.3 | 20.2 | 672 | 19.1 | 21.0 | 705 |
| 3*16+1*6 | 20.6 | 22.5 | 921 | 20.3 | 21.2 | 947 |
| 3*16+1*10 | 21.2 | 23.0 | 928 | 21.6 | 23.5 | 1000 |
| 3*25+1*10 | 25.0 | 26.8 | 1388 | 25.5 | 27.3 | 1417 |
| 3*25+1*16 | 25.5 | 27.4 | 1476 | 26.0 | 27.8 | 1491 |
| 3*35+1*10 | 27.7 | 29.5 | 1723 | 28.9 | 30.8 | 1770 |
| 3*35+1*16 | 28.2 | 30.0 | 1811 | 29.4 | 31.3 | 1847 |
| 3*50+1*25 | 32.6 | 34.5 | 2503 | 33.6 | 35.5 | 2550 |
| 3*70+1*25 | 36.2 | 38.1 | 3218 | 37.3 | 39.1 | 3258 |
| 3*70+1*35 | 36.9 | 38.7 | 3329 | 38.1 | 39.9 | 3374 |
| 3*95+1*35 | 41.9 | 43.7 | 4351 | 43.1 | 44.9 | 4400 |
| 3*95+1*50 | 42.6 | 44.5 | 4528 | 43.8 | 45.7 | 4579 |
| 3*120+1*35 | 45.0 | 46.8 | 5144 | 46.4 | 48.2 | 5194 |
| 3*120+1*50 | 45.7 | 47.6 | 5319 | 47.1 | 49.0 | 5370 |
| 3*150+1*50 | 50.0 | 51.8 | 6349 | 51.2 | 53.0 | 6410 |
| 3*185+1*50 | 54.6 | 56.9 | 7644 | 55.8 | 58.1 | 7706 |
| Note: Data above only for reference.confirmation needed by our technical department. We reserve the right to alter all information without notice. | ||||||
